QualArc PCSDB-MD Assembly/Installation Instructions

PARCEL CHEST ASSEMBLY & INSTALLATION INSTRUCTIONS
Thank you for your purchase of the PARCEL CHEST package delivery system.
Please read these assembly instructions in full before you begin. A step-by-step
assembly video is available online. Note, extra screws are included, so you may have
screws remaining after assembly.
Step 1: Locate the front, back, sides, bottom and lid (see images below). It is important
Step 2: To make assembly easier, tap the holes on the inside of all the parts (except
Figure 1
Step 3: Locate the back panel and insert the lip of the back panel under the lip of
Step 4: Locate the right side panel. Make sure the 2 holes on top of this panel
Figure 2
Step 5: Using the same method as Step 4, locate the left side panel and attach it to
Step 6: For this step, a helper is recommended. Locate the front panel. Make sure the
Figure 3
Figure 4
Figure 5
that the bottom is assembled as shown in the photos. If you reverse the bottom,
the unit will not assemble properly. For best results, assemble the parcel box on
a level surface.
lid and top of the back panel) using the sheet metal screws. Caution: Do not
pre-tap the threaded holes located on the lid and the top of the back panel or
you will strip out the threads. Be careful not to over-tighten the screws. Now
that the holes are tapped, remove the screws and begin assembly.
the bottom panel. Make sure the 3 holes in bottom panel line up with the
holes in the back panel. Insert 3 sheet metal screws and thread them into
the holes (do not fully tighten the screws). (Figure 1)
are pointed up (if rubber bumper is attached, it should be at the top of this
panel). Slide the right side panel behind the lip of the back panel and under
the lip of the bottom panel. Fasten the right side panel to the back panel
with 5 sheet metal screws (do not fully tighten the screws). Do not fasten the
right panel to the bottom panel yet. (Figure 2)
the back panel. (Figure 3)
rectangular hole on top of this panel is pointed up. Spread the left and right
panels open slightly from the bottom panel. With these panels spread open,
insert the front panel under the lip of the bottom panel and in behind the left
and right side panels. Fasten the front panel to the left and right panels with
10 sheet metal screws (5 screws for each side panel)(do not fully tighten the
screws). (Figures 4 & 5)
Sheet Metal
Screw
1/2" Machine
Screw
1/4" Machine
Screw
Masonry
Anchor Bolt
QualArc
916-273-1576
Fax 916-635-0228
www.qualarc.com
Shim
