Summary of Contents for Precision UK CPX-A Area Alarm
- Page 1 The CPX Area Alarm Precision UK Ltd, CPX Technology Building, Pepper Road, Hazel Grove, Stockport SK7 5BW Tel: +44 (0)161 487 2822 Fax:+44 (0)161 487 2822 www.precisionuk.co.uk...
- Page 2 Introduction The CPX-A area alarm panel is designed to monitor high & low pipeline pressure on up to 6 gases, using volt-free, normally closed, contacts on pressure sensors mounted in the pipeline downstream from the final Area Valve Service Unit (AVSU).
- Page 3 If the panel is to be connected to a CPX-P system, a 2 core screened cable, minimum 0.5 square mm, is required between the panel and the nearest point on the CPX-P system. Notes All cable screens must be connected at both ends. Continuity must be maintained through any junction boxes.
- Page 4 Setting up Set the set-up jumpers as follows (the settings are shown on the label in the back box):- Number of Gases: You will not normally need to change these. Pressure Switches: Enable these if you are connecting to pressure switches via a termination box Audible: Set to EN475 to enable the European standard audible type, or HTM02 to enable the HTM02 audible type.
- Page 5 present. Operate the lockout button. Replace the cover. You can check which alarm conditions are locked out by pressing the mute/test button. Any alarm condition which is locked out will not flash. Any other alarm conditions will flash. Note. A system fault cannot be locked out.
- Page 9 Precision UK Ltd CPX Technology Building Pepper Road Hazel Grove Stockport SK7 5BW United Kingdom Product Type CPX-A Area Alarm Year of Manufacture 2013 Standards Conform to: BS EN 50081-1 BS EN 50082-1 BS EN 61000-3-2 BS-EN60950 Authorised Representative : K.
