Modem Set-up Instruction
Automatic Installation
●
Please make sure to plug in the NTT modem
to the optical fiber jack and power cable
before automatic installation.
On-site Installation
●
Please make sure that the NTT modem is
plugged in to the optical fiber jack and the
power cable, and the modem is turned on
after the installation is completed.
●
No particular settings are required for IPv6 Internet connection.
●
IPv6 Internet service will usually become available within 2-3 hours to up to 6
hours after the installation. (*It may take up to 24 hours during system
maintenance. )
If you want to start using the Internet before IPv6 signal is recieved, please
●
follow the instruction for "How to setup IPv4 ID and password" on page 3.
(Hero v6plus)
Optical fiber cable
Power cable
Optical fiber
socket type
Look for a socket for
optical fiber. Insert
the white fiber cable
into the socket circled
in red.
5/10/2018
1
Advertisement
Table of Contents
Summary of Contents for HeroNet Hero v6plus
- Page 1 5/10/2018 Modem Set-up Instruction (Hero v6plus) Automatic Installation ● Please make sure to plug in the NTT modem to the optical fiber jack and power cable before automatic installation. Optical fiber cable On-site Installation ● Please make sure that the NTT modem is Power cable plugged in to the optical fiber jack and the power cable, and the modem is turned on after the installation is completed. ● No particular settings are required for IPv6 Internet connection. ● IPv6 Internet service will usually become available within 2-3 hours to up to 6 hours after the installation. (*It may take up to 24 hours during system maintenance. ) If you want to start using the Internet before IPv6 signal is recieved, please ● follow the instruction for “How to setup IPv4 ID and password” on page 3. Optical fiber socket type Look for a socket for optical fiber. Insert the white fiber cable into the socket circled in red.
- Page 2 ● “PPP” will be turned off once the IPv6 signal is sent to the modem. NTT Modem ルーター電源 (ONU) ① Router power アラーム ② Alarm RS500MI/ RS500KI ③ PPP ひかり電話 ④ Phone line ⑤ ACT Restart ⑥ Registration 登録 Reset Optical fiber cable 初期状態 ⑦ Initial state オ プ シ ョ ン ⑧ Option Power cable What to do when the Internet is not working ● Check the optical fiber cable and power cable are plugged into the socket and the modem properly. ● Press the restart button on the modem to restart the modem. If you need assistance, please call HeroNet for technical support. ● HeroNet 0176-53-5136 helpdesk@heronet.ne.jp...
- Page 3 Configuration guide for IPv4 (Optional) No particulr settings are required before starting Internet with IPv6 connection because the connection signal for IPv6 will be automtically sent to your modem. If you want to start using the Internet before the IPv6 signal comes, you can set up IPv4 connection and start using the Internet before the IPv6 signal reaches the modem. *The modem usually receives the IPv6 signal within 2-3 hours to up to 6 hours after the installation. (It may take up to 24 hours during system maintenance.) *Please restart the modem if you still cannot connect to the internet. *If restarting the modem does not work, please call HeroNet for technical support. Please plug in the NTT modem, and the modem to your computer by LAN cable. NTT modem If you donʼ t have LAN cable, see wireless set-up instruction first and connect your PC to the NTT device wirelessly. Turn on the computer, open the internet browser such as Internet Explorer, Google Chrome, Firefox, Safari, and enter http://192.168.1.1/ or http://ntt.setup/ , and hit Enter. ...
- Page 4 Enter NTT modemʼ s password as ②〜④ below. Note: If you forgot the NTT modem's password, plug the power cord as you pressing the Reset （“初期化”） button at the front of the modem and wait for a few minutes. The window below appears prompting for a "User Name" and "Password". ⑤~⑦...
- Page 5 The NTT modem 's web-based setup page appears, enter "username" and "Password" which were provided by HeroNet. ⑧〜⑫ If all the information entered in STEP 5 is correct, green light for PPP on NTT modem will be turned on, and the Internet is now ready to use. *NTT modem will be restarted after the alarm light turns off. Please wait until the PPP light turn The alarm light might turn red after PPP light turns green. Please leave it on until the alarm light turns off. Please do not click anything on the setting page on the Internet browser.
- Page 6 How to use Wi-Fi Please check the information on the back of the NTT modem as below. SSID-1, 2 IEEE802.11b/11g/11n 2.4 GHz SSID-3 IEEE802.11a/11n/11ac 5 GHz Please select one of the SSID from the list on your wireless device. Please enter the security key for the SSID you selected on STEP2. Please open your browser and check if you can use Internet. *If you would like to use your own Wi-Fi router, you can do so by connecting your router to the Internet gateway by Access Point (AP) mode. Please follow the manufacturerʼ s instruction or website for more information. We cannot guarantee proper operation of your router when you connect your own router. ...
