SMB S Series Technical Information

Technical Information

Trampoline "S"
Page 1

Installation instructions

Maintenance instructions EN 1176-1

26.08.11

General

The work described must be carried out by a qualified person.
Due to the heavy weight of the completed trampoline, no further anchorage is necessary.
The trampoline is designed to be used on ground level.

Dimensions

Overall size
Minimum space
Jumping area
Clearance
Max. free drop height:

Age suitability

3 years and older

Number of users

1 person

Composition of the ground

Please refer to DIN EN 1176-1 for ground conditions in the play area.
We recommend a covering with shock-absorbing qualities like grass or synthetic surface. Sand,
bark mulch or wood chips aren't able, while they can fall into the trampoline and decrease the
play function.

Installation tools

Tools supplied:
4 off Supporting iron rings
1 off Tool to assemble and/or remove jumping mats
List of supplied / Packing units
1 Palett
EN 1176-1
1.25 x 1.25 m
3.25 x 3.25 m
0.75 x 0.75 m
1.50 m
0.60 m
Figure 1 Trampoline S
