Afriso EURO-INDEX RG 210 Instruction Manual

Level controller

Advertisement

Quick Links

Instruction Manual
Level Controller
RG 210
# 53206
Read manual before use!
Observe all safety information!
Keep manual for future use!
01.2009 0
854.001.0149
Mess-, Regel- und
Überwachungsgeräte
für Haustechnik,
Industrie und Umweltschutz
Lindenstraße 20
DE-74363 Güglingen
Telefon: +49(0)7135-102-0
Service: +49(0)7135-102-211
Telefax: +49(0)7135-102-147
E-Mail: info@afriso.de
Internet: www.afriso.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG 210 and is the answer not in the manual?

Questions and answers

Summary of Contents for Afriso EURO-INDEX RG 210

  • Page 1 Industrie und Umweltschutz Lindenstraße 20 DE-74363 Güglingen Telefon: +49(0)7135-102-0 Service: +49(0)7135-102-211 Telefax: +49(0)7135-102-147 E-Mail: info@afriso.de Internet: www.afriso.de Instruction Manual Level Controller RG 210 # 53206 Read manual before use! Observe all safety information! Keep manual for future use! 01.2009 0 854.001.0149...
  • Page 2: Table Of Contents

    Commissioning the device................16 Function test ....................17 Operation .......................17 Maintenance ......................17 Maintenance intervals.................17 Maintenance activities ................18 Troubleshooting .....................18 10 Shutting down and disposal...................19 11 Spare parts and accessories .................19 12 Warranty ........................20 13 Copyright........................20 14 Customer satisfaction ....................20 15 Addresses ......................20 RG 210...
  • Page 3: This Instruction Manual

    Explanation of symbols and typeface Symbol Meaning Prerequisite for an activity Activity consisting of a single step Activity consisting of several steps Result of an activity • Bulleted list Text Indication on a display Highlighting Highlighting RG 210...
  • Page 4: Safety

    2 Safety Intended use The RG 210 level controller may only be used as a level switch, as level control for filling or as level control for emptying for liquids. The RG 210 level controller detects minimum or maximum levels and switches pumps or valves to control levels of liquids.
  • Page 5: Safe Handling

    Electrical work may only be carried out by qualified electricians in accordance with local and national regulations. Modifications to the product Changes or modifications made to the product by unauthorised per- sons may lead to malfunctions and are prohibited for safety reasons. RG 210...
  • Page 6: Use Of Spare Parts And Accessories

    The output signal is available as a voltage-free relay contact (1 changeover contact). RG 210 can be operated with the type 937 and type 150 PTC ther- mistor probes. The PTC thermistor probes are not included with the RG 210.
  • Page 7: Operating Modes

    Operating mode "Filling": level control for filling Both PTC thermistor probes "Probe 1" and "Probe 2" must be con- nected. The following applies to both probes in this operating mode: If the PTC thermistor is exposed to air (not submerged in a liquid) RG 210...
  • Page 8 15 seconds prevents a release before the heat-up phase is completed. RG 210 can be operated with or without additional external devices. The following types of additional devices can be used: visual and audible alarm units, telecommunication devices, building control sys- tems, building automation systems, pumps, valves, etc.
  • Page 9: Application Examples

    Fig. 4: Application as level switch Pump On/Off RG 210 Probe 1 Probe 2 Maximum level Minimum level Fig. 5: Application as level control for filling/emptying 1 RG 210 2 AFRISO event reporting system 3 Internet 4 Email 5 Mobile phone 6 Fax 7 Phone Fig.
  • Page 10: Specifications

    M 100 mA (5 x 20 mm) Breaking capacity output relay Max. 250 V, 2 A, resistive load Electrical safety Electrical safety EN 61010 Protection class DIN 57700 Protection IP 30 EN 60529 Electromagnetic compatibility (EMC) Noise suppression EN 61000-6-3 Noise immunity EN 61000-6-2 RG 210...
  • Page 11 Parameter Value General specifications Dimensions (Ø x L) 14 x 57 mm Weight 130 g Screw connection Plastic, R1“, 1 bar Weight Brass, Ø x L = 12 x 40 mm Probe housing Plastic, Ø = 14 mm RG 210...
  • Page 12: Approvals, Tests And Conformities

    Max. DC 12 V Electrical safety Protection IP 68 EN 60529 Approvals, tests and conformities RG 210 conforms to the EMC Directive (89/336/EEC and 92/31/EEC) and the Low Voltage Directive (73/23/EEC and 93/68/EEC). 5 Transportation and storage CAUTION Damage to the device due to improper transportation.
  • Page 13: Installation And Commissioning

    Refit the grey upper part of the housing to the black base and fasten it with the two housing screws. Make sure the contact bar of the printed circuit board does not damage the contact springs of the black base. RG 210...
  • Page 14: Electrical Connection

    The probe head must not float in the liquid. Electrical connection Mains supply is disconnected and cannot be switched back on by accident. Release Probe 1 Probe 2 Wiring diagram in housing Pump Fig. 7: Electrical connection RG 210...
  • Page 15 Standard screened cable 2 x 0.5 mm² can be used to extend the probe cable. The maximum length of the extension cable is 50 m. Output The output signal of RG 210 is made available via a voltage-free re- lay contact (1 changeover contact). The connection cable must be permanently installed.
  • Page 16: Selecting The Operating Mode

    Desired operating mode has been selected. Control unit housing has been closed with screws. If all prerequisites are met, the device is ready for operation. Switch on the power supply via the on-site mains fuse. The connected PTC thermistor heats up. RG 210...
  • Page 17: Function Test

    The function sequence must correspond to the description of the selected operating mode in chapter 3.1, page 7. Operation RG 210 automates the control of pumps and valves. The operation of the RG210 is limited to its regular monitoring: •...
  • Page 18: Maintenance Activities

    Mains fuse de- Replace the mains state. fective. fuse, refer to chap- ter 8.2, page 18. Wiring defective. Check wiring. Probe(s) defec- Check probe(s). tive. PTC thermistor is Replace probe(s). polluted (deposits). RG 210...
  • Page 19: Shutting Down And Disposal

    Mains fuse F1 (M 100 mA) 941571 0100 RC combination (0,1 µF/100 Ohm) 618 001 5100 Brass weight for probe installation 16 00 020901 Clamp for probe installation 16 00 101001 Event reporting system Phone Alarm SD1 90003 RG 210...
  • Page 20: Warranty

    Customer satisfaction is our prime objective. Please get in touch with us if you have any questions, suggestions or problems concerning your product. 15 Addresses The addresses of our worldwide representatives can be found on the Internet at www.afriso.com. RG 210...
