Arch Tray NG2
Insert
DECORATIVE FUEL EFFECT GAS FIRE
For Use With Gallery Cast Iron Insert (s)
THIS PRODUCT IS NOT SUITABLE FOR
PRIMARY HEATING PURPOSES
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. GATCXXMN is for use on Natural Gas (G20) at a supply
pressure of 20 mbar in G.B. / I.E.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for BFM Gallery Arch Tray NG2 Series
- Page 1 Arch Tray NG2 Insert DECORATIVE FUEL EFFECT GAS FIRE For Use With Gallery Cast Iron Insert (s) THIS PRODUCT IS NOT SUITABLE FOR PRIMARY HEATING PURPOSES Installation, Maintenance & User Instructions Hand these instructions to the user Model No. GATCXXMN is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B.
-
Page 2: Table Of Contents
Conditions of Installation / About Your New Gas Fire Operating the Fire Cleaning the Fire Section 6 Trouble Shooting Charts Burner will not light Burner will not stay lit when control knob is released This appliance is manufactured by :- BFM Europe Ltd. Trentham Lakes, Stoke-on-Trent, ST4 4TJ... -
Page 3: Information And Requirements
SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Model GATCXXMN Gas Type Main injector (1 off) Size 500 Cat 82 Burner Type Aeromatic Self Vitiating Tubular Burner Max. Gross Heat Input : 6.9 kW Min. Gross Heat Input & 2.5 kW Ignition Rate : Cold Pressure : 20.0 +/-1.0 mbar... -
Page 4: Conditions Of Installation
INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution. -
Page 5: Fireplace / Surround Suitability
FIREPLACE / SURROUND SUITABILITY The fire must only be installed on a hearth it must not be installed directly onto carpet or other combustible floor materials. The fire is suitable for fitting to non-combustible fire place surrounds and proprietary fire place surrounds with a temperature rating of at least 150 o c. If a heating appliance is fitted directly against a wall without the use of a fire surround or fire place all combustible material must be removed from behind the trim. -
Page 6: Fire Place Opening / Catchment Space
Check the chimney pot / terminal and general condition of the brickwork or masonry. If the chimney or flue is in poor condition or if there is no up-draught do not proceed with the installation. If there is a history of down-draught conditions with the chimney / flue, a tested and certificated flue terminal or cowl suitable for the relevant flue type should be considered. - Page 7 Table A - Installation Depth Requirements for a Gallery Arch Tray being installed with a Gallery Casting, requiring 12.0 litres of debris collection volume (fig. 2). Opening Width (mm) Minimum Depth Required (mm) 560 (minimum opening width) See fig. 2 below for explanatory diagram. Fig.
-
Page 8: Fitting To Chair Bricks
1.7 FITTING TO FIREPLACES WITH EXISTING CHAIRBRICKS AND CONVENTIONAL BRICKBUILT CHIMNEYS This appliance is not suitable for use in fireplaces fitted with an existing chairbrick. Any chairbrick must be removed prior to proceeding with the installation 1.8 FITTING TO PRE-FABRICATED TWIN WALL METAL FLUE BOXES The appliance may be fitted to twin wall metal flue boxes conforming to the con- structional requirements of BS 715 / BS EN 1856-2, (for example the Ritevent LFE 175 box). -
Page 9: Installation Of Fire
SECTION 2 INSTALLATION OF FIRE UNPACKING THE FIRE Carefully lift the fire out of the carton. Remove the loose item packaging carefully from the front of the appliance. Check the contents as listed :- Packing Check List - Coal Fuelbed Models 1off Fire tray / burner assembly 1off... - Page 10 IMPORTANT NOTE : IF THE CASTING THAT YOU ARE FITTING THIS TRAY BURNER INTO HAS A SLOT IN THE REAR FACE, THIS SLOT MUST BE SEALED WITH SUITABLE SEALING TAPE. FAILURE TO SEAL THIS SLOT CAN LEAD IN SOME FLUE CIRCUMSTANCES TO FLAME REVERSAL WHICH WILL DAMAGE THE CONTROLS.
- Page 11 Carefully withdraw the fire base from the opening to enable the gas supply and fire fixing to be completed. Drill 2 off fixing holes as marked out in section b) to accomodate 2 off no. 10 or 12 rawl plugs Fit the rawl plugs (supplied) Fig.
-
Page 12: Gas Tightness And Inlet Pressure
Making the gas connection The gas connection should be made to the appliance inlet elbow using rigid 8mm piping. Lift the firebase in to position and secure the base of the fire opening with the two screws provided, ensure when fitted that the fire tray sits level. -
Page 13: Assembling Fuel Bed And Commissioning
SECTION 3 ASSEMBLING FUEL-BED AND COMMISSIONING ASSEMBLING THE FUEL-BED - Coal Fuelbed Model a) Place the fuelbed base centrally on to the fuelbed support and push fully backwards to the rear face of the cast iron back panel, ensuring the locating groove in the fuel-bed fits onto the raised channel in the fuel-bed support as shown in Fig 6. - Page 14 COAL LAYOUT IMAGES SHOWN WITHOUT CAST BARS IN POSITION TO ALLOW CLARITY OF IMAGES Fit five of the coals along the front row of the fuelbed matrix, as shown in Fig. 7 below. Fig. 7 Fit three off coals into the recess’s on the rear edge of the fuelbed, as shown in fig.
- Page 15 Fit four of the coals into the space between the front and rear row of coals as shown below in Fig. 9 Fig. 9 Fit the two remaining coals at each end of the second row of coals, as shown below in Fig. 10 Fig.
-
Page 16: Lighting The Appliance
To ensure that the release of fibres from these R.C.F (Refractory Ceramic Fibre) articles is kept to a minimum, during installation and servicing we recommend that you use a HEPA filtered vacuum to remove any dust accumulated in and around the appliance before and after working on the appliance. -
Page 17: Checking For Clearance Of Combustion
CHECKING FOR CLEARANCE OF COMBUSTION PRODUCTS Close all doors and windows in the room. Light the fire and allow to run for approximately 5 minutes on high position. After approximately 5 minutes hold a smoke match just inside and below the centre of the lower front edge of the top of the fire. (It is recommended that a suitable smoke match holder is used when check ing for clearance of combustion products). -
Page 18: Maintenance
SECTION 4 MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a registered engineer. This is a condition of the Gallery guarantee schemes. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney. -
Page 19: Removal Of The Control Tap
Removing the Control Tap from the fire. 4.3.1 Remove the burner assembly as in section 4.1. 4.3.2 Pull the control knob off the control tap spindle. 4.3.3 Loosen and remove the two gas pipe retaining nuts from the control tap and release the ends of the gas pipes from the control tap body. Remove the push in thermocouple from the end of the control tap. -
Page 20: Conditions Of Installation / About Your New Gas Fire
SECTION FIVE - USER INSTRUCTIONS About your Arch Tray The Arch Tray incorporates a unique and highly developed fuel bed which gives the realism of a loose coal layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuel-bed components ensures long and trouble free operation. -
Page 21: 5.2 Operating The Fire
The ceramic fuel-bed remains hot for a considerable period after use and sufficient time should be allowed for the fire to cool before cleaning etc. The fire must only be operated with the cast surround supplied with the fire. 5.2 Operating the Fire The controls are located behind the ashpan cover which is situated below the cast front. -
Page 22: Cleaning The Fire
the previous section. In the event of repeated operation a registered gas installer must be called to investigate and rectify the cause. 5.3 Cleaning - WARNING Before attempting any cleaning operation ensure that the fire has been allowed to fully cool. Black painted metal parts should be gently cleaned with a damp cloth. Cleaning the Fuelbed We do not recommend cleaning of the coals or fuelbed components as these are fragile and damage may result. -
Page 23: Burner Will Not Light
SECTION SIX - TROUBLE SHOOTING CHARTS When Burner Will Not Light Ensure no debris is evident in pilot flame strip on burner (e.g. soot deposits, fluff etc.) which could cause a short circuit. If so, clean the flame strip area on the burner with a HEPA filtered vacuum cleaner to remove debris. -
Page 24: Burner Will Not Stay Lit When Control Knob Is Released
When Burner Will Not Stay Lit Once Manual Valve is Released If the burner extinguishes during continuous use, this may be indicating that the oxygen depletion sensor is operating, do not use the product until a registered installer has inspected the product and the cause rectified Ensure no debris is evident in pilot flame strip on burner (e.g. -
Page 25: Bfm Europe Ltd
Due to our policy of continual improvement and development the exact accuracy of descriptions and illustrations cannot be guaranteed. Part No. B-1004282 Issue 2 BFM Europe Ltd. Trentham Lakes Stoke-on-Trent Staffordshire ST4 4TJ www.bfm-europe.com Telephone - General Enquiries : (01782) 339000...
