Summary of Contents for Applied Strobe AST-14
- Page 1 INSTALLATION INSTRUCTIONS-ULC APPROVED MODEL AST-14 HAZARDOUS LOCATION STROBE WARNING LIGHT APPLIED STROBE TECHNOLOGY CO. LTD. 8345 Stanley Avenue, Niagara Falls, On L2G 0C8 905-374-3077 FAX 905-374-6114 E-mail: support@appliedstrobe.com Ast-14 Ver. No.1 Oct. 2009...
- Page 2 MOUNTING The Ast-14 strobe is designed for mounting to ¾” conduit and may be mounted in any position. Prior to mounting the strobe , ensure that the threads on both the pipe and strobe fixture are clean. Thread the strobe onto the ¾”...
- Page 3 1 Ground screw 2 Strain relief disk 3 Wrap wires once around strain relief 4 3/4 14 N.P.T 5 Power wires: 2 Black (-) and 2 Red (+) 6 1/4 - 20 Set screw Figure1 Oct 2009...
- Page 5 Strobe Wiring Diagram To ULC To other Listed Fire Strobe Alarm Control or EOL Panel Resistor Listed Listed Strobe Strobe Light Light NOTES 1. Leads 16 AWG , minimum 152 mm long 2. For electrical supervision use in and out leads as shown Figure 2 Oct 2009...
