Klima1stKlaas PD60RB Instruction Manual

Design dehumidifier 60 litres
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction manuel
design dehumidify 60 liter
PD60RB
www.klima1stklaas.de
In the complaint case you turn please always to our hotline. A return of the article
in the sales place is not possible. We offer a nationwide service for maintenance
and repair within the scope of the guarantee.
Please contact us:
Hotline for Germany: 0900 1 850 280
(0,49 €/Min. german telefon network „Telekom", mobil call cost are different)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD60RB and is the answer not in the manual?

Questions and answers

Summary of Contents for Klima1stKlaas PD60RB

  • Page 1 Instruction manuel design dehumidify 60 liter PD60RB www.klima1stklaas.de In the complaint case you turn please always to our hotline. A return of the article in the sales place is not possible. We offer a nationwide service for maintenance and repair within the scope of the guarantee.
  • Page 2 Monday until Friday 08.00 am until 5.00 pm In the complaint case you turn please always to our hotline. A return of the article in the sales place is not possible. Information about our products or accesoires are also available at: www.klima1stklaas.de...

  • Page 3: Safety Information

    SAFETY INFORMATION After transporting or tilting (angled positions) the device, do not plug into the power socket for least 4 hors. Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place. Never immerse the appliance in water or other liquids.
  • Page 4 PARTS OF DEHUMIDIFIER 1. Control panel 2. Adjustable air vent 3. Top cover 4. Side panel 5. Front panel top 6. Front panel bottom 7. Filter suction grate 8. Panel back 9. Condensate drainage hose 10. Condensate drainage plug 11. Back castors 12.

  • Page 5: Operation Instruction

    CONTROL PLATE DESCRIPTION OPERATION INSTRUCTION Starting the unit 1. Firstly, turn the humidity control switch to the “OFF” position. 2. Plug in the dehumidifier. 3. Turn on the humidity control switch (to right side) and turn the same switch to the reading of the desired humidity (60% in general as shown on position“6”).
  • Page 6 PRECAUTIONS 1. The dehumidifier shall not operate if the humidity setting is higher than the ambient humidity. 2. Drain the water in the water storage tank when the water in the tank is full and the water level indicator light illuminates. And then install the empty water tank back to its position, so the unit can continue its operation.

  • Page 7: Installing The Drainage Hose

    INSTALLING THE DRAINAGE HOSE The drainage hose can be put … or through a hole made in the wall. through a slit in the window or round a door…. … or through a vent made at Notice that the drainage hose must not be installed more the bottom of the door or in the than 1.8 meters higher than the unit.

  • Page 8: Special Features

    SPECIAL FEATURES 1. Automatic dehumidify After setting up the desired humidity, the unit will be automatic running or stopping operation and maintain the desired humidity. 2. Adjustable humidity control The unit provided with the adjustable humidity button, and relative humidity is from RH40% to RH80%. 3.
  • Page 9 Physical Basics (humidity ratio in ambient air by 100% air humidity) Water quantity ( g/m³) by saturated humidity Room temperature in ° C in air 3,32 10,7 12,1 13,7 15,4 17,3 19,5 21,8 24,4 27,2 30,4 33,8 • The lower the ambient temperature is and the colder the outside temperature is, the less moisture is stored in the air and flows into the room to be dried.

  • Page 10: Specification

    SPECIFICATION...

  • Page 11: Troubleshooting

    Klaas Direktimport GmbH, Köllertalstrasse 47 D- 66265 Heusweiler You can find spare parts fort he model www.klima1stklaas.de In the complaint case you turn please always to our hotline. A return of the article in the sales place is not possible.
  • Page 12 Klima1stklaas, by Klaas Direktimport GmbH Köllertalstraße 47, D-66265 Heusweiler 9.warranty card O-Nr.: 01/11 1. your adress Company name: Contact person: Last name: First name: street: zip code: city: telephone number.: fax number.: e-mail: 2. product information model: Model number: 3. Purchase...
