Summary of Contents for Elliott Roto-Jet II Series
- Page 1 Roto-Jet II 0650 / 0650R (110V) & 0750 / 0750R (220V) Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions www.elliott-tool.com...
-
Page 3: Table Of Contents
Table Of COnTenTs Introduction ......................4 Safety Guidelines ....................5 Grounding Instructions ..................6 Start-Up ........................ 8 Operation Instructions ..................9 Parts List & Diagrams ..................10 Maintenance Instructions ................... 18 Troubleshooting ....................19 Flexshaft Repair ....................21 Technical Information ..................22 Warranty ...................... -
Page 4: Introduction
InTRODUCTIOn Thank you for purchasing this Elliott product. More than 100 years of experience have been employed in the design and manufacture of this control, representing the highest standard of quality, value and durability. Elliott tools have proven themselves in thousands of hours of trouble-free field operation. -
Page 5: Safety Guidelines
• Do not operate the machine if there appears to be damage to the machine, if screws are loose or missing, or if performance appears to be unsatisfactory. • Never use your Elliott Roto-Jet II®, or any other power tool when under the influence of drugs, alcohol or medication that decreases concentration and impairs operator control. -
Page 6: Grounding Instructions
GROUnDInG InsTRUCTIOns This machine must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a GFI plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. - Page 7 GFI plug that may cause a fault. 6. If the GFI still cannot complete the cycle described in steps 2 through 4 above and after checking the items in step 5,the unit is not functioning. Contact Elliott for repairs. Roto-Jet II...
-
Page 8: Start-Up
Unpacking Your Elliott Roto-Jet II® is shipped in a well-packed carton with the electric supply cord attached and the foot pedal detached. Upon receiving your new machine, inspect the unit for damage. If damage is discovered notify Elliott and the carrier. DO NOT discard the carton or any packaging. Inspectors will need to examine both the carton and the contents. -
Page 9: Operation Instructions
OPeRaTIOn InsTRUCTIOns 1. Using your Elliott catalog or the Elliott Product Selection CD, select the appropriate flexible shaft and cleaning attachments for the tube size and conditions. Thread the cleaning device into the tool coupling of the flexible shaft. TOOL TIP: When using a reversing direction drive Roto-Jet II®, install a ¼” lock washer between the tool coupling and the cleaning device. -
Page 10: Parts List & Diagrams
PaRTs lIsTs & DIaGRaMs 0650 Parts list Item # Part Name Part Number Cover with Handle 06511702 Base 06519701 Cover Screw 06520105 Switch Guard 06520217 Switch Assembly 06520120 Power Cord with GFCI 06515021 Motor 06515010 Mounting Bolt Sets 06520106 Circuit Board (110V) 06515001 Short Water Hose 06550042... - Page 11 PaRTs lIsTs & DIaGRaMs 0750 Parts list Item # Part Name Part Number Cover with Handle 06511702 Base 06519701 Cover Screw 06520105 Switch Guard 06520217 Switch Assembly 06520120 Power Cord 07515021 Motor 06515010 Mounting Bolt Sets 06520106 Circuit Board (220V) 07515001 Short Water Hose 06550042...
- Page 12 PaRTs lIsTs & DIaGRaMs 0650R Parts list Item # Part Name Part Number Cover with Handle 06511702 Base 06519701 Cover Screw 06520105 Switch Guard 06520217 Switch Assembly 06520120 Power Cord with GFCI 06515021 Motor 06515010 Mounting Bolt Sets 06520106 Reversing Circuit Board (110V) 06519174 Short Water Hose 06550042...
- Page 13 PaRTs lIsTs & DIaGRaMs 0750R Parts list Item # Part Name Part Number Cover with Handle 06511702 Base 06519701 Cover Screw 06520105 Switch Guard 06520217 Switch Assembly 06520120 Power Cord 07515021 Motor 06515010 Mounting Bolt Sets 06520106 Reversing Circuit Board (220V) 07519174 Short Water Hose 06550042...
- Page 14 PaRTs lIsTs & DIaGRaMs 0650 anD 0750 PaRTs DIaGRaM Roto-Jet II...
- Page 15 PaRTs lIsTs & DIaGRaMs 0650R anD 0750R PaRTs DIaGRaM Roto-Jet II...
- Page 16 Roto-Jet II...
- Page 17 Roto-Jet II...
-
Page 18: Maintenance Instructions
MaInTenanCe InsTRUCTIOns Before Each Use 1. Inspect your Roto-Jet II® for any obvious damage or missing parts. 2. Check the power cord for cracks or wear. 3. Test the GFI plug to insure proper functioning. 4. Inspect the manifold o-ring. Replace if necessary. 5. -
Page 19: Troubleshooting
• Measure the internal diameter of the tube beyond the expanded portion of the tube end. With the exception of the Elliott Turbo Brush®, Flexible Shaft coils when cleaning cleaning devices should not be sized larger than the tube ID. - Page 20 • This may be caused by the shaft being bent at too sharp of a radius. • Flexible shaft is too short for the tube being cleaned. Contact Elliott for the correct shaft length. Flexible Shaft prematurely breaks NOTE: The flexible shaft should not be bent at sharp angles. That near the drive coupling.
-
Page 21: Flexshaft Repair
RePaIR Flexshaft Repair Instructions Instructions for both the Tool and Motor Couplings Using the Elliott Crimping Block Assembly Part Number W900-00 1. Cut the outer casing back approximately 1” for clearance to allow the core to be cleaned up at the break. Grind the end of the core taking care not to overheat the wire strands. -
Page 22: Technical Information
TeCHnICal InfORMaTIOn 0650 & 0650R Motor 1/2 HP DC Motor Power Supply 115 Volt / 50-60 Hz 6 Amps Fuse 10 Amp Shaft Speed 0 to 1800 RPM Adjustable Dimensions 22” L x 11” W x 10” H Weight 35 lbs. Water Input Garden Hose 0750 &... -
Page 23: Warranty
WaRRanTy Should any part, of Seller’s own manufacture, prove to have been defective in material or workmanship when shipped (as determined by Seller), Seller warrants that it will, at its sole option, repair or replace said part f.o.b., point of manufacture, provided that Buyer notifies, in writing, of such defect within twenty-four (24) months from date of shipment from the manufacturing plant. - Page 24 Roto-Jet II...
- Page 26 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Locally Supported By: Contact us or your local support. Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 www.elliott-tool.com/support Phone: +1 937 253 6133 • +1 800 332 0447 Fax: +1 937 253 9189 www.elliott-tool.com...
