- Page 1 Soot Buster Fire Tube Boiler Cleaner Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions www.elliott-tool.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ......................4 Safety Guidelines ....................5 Receiving & Installation ..................7 Operation ......................8 Specifications ....................... 9 Part Numbers & Diagrams .................. 10 Troubleshooting Guide ..................11 General Tips ....................... 12 Warranty ......................13... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing this Elliott product. More than 100 years of experience have been employed in the design and manufacture of this control, representing the highest standard of quality, value and durability. Elliott tools have proven themselves in thousands of hours of trouble-free field operation. -
Page 5: Safety Guidelines
• Know Your Elliott Tool. Read this manual carefully to learn your tool’s application and limitations as well as the potential hazards specific to this tool. - Page 6 Follow instructions for lubrication, maintenance and changing accessories. For more information see “Maintenance” section. Periodically inspect the tool cord and extension cords for damage. Have damaged parts repaired or replaced by an Elliott service facility. • Store Idle Tools. When not is use, store your tool in a dry, heated, secured place. For more information see “Maintenance”...
-
Page 7: Receiving & Installation
RECEIVING & INSTALLATION Unpacking The Elliott Soot Buster is shipped in a carton complete with all accessories listed. On arrival, check for external damage to the box. If damage is found, notify the carrier and the supplier so insurance inspectors can examine the box before it is unpacked. When opened, check the contents against the packing and parts list. -
Page 8: Operation
7. At the end of the tube, the Soot Buster will stop advancing. Mark the hose at your end with tape, to give you a good indicator of when the Soot Buster is at the end of the tube. 8. Without switching off the air, give the hose a firm pull. This will reverse the Soot Buster returning itself to you. -
Page 9: Specifications
SPECIFICATIONS Soot Buster Specifications System Specifications M5784-00 M5784-01 M5784-02 2” - 3” 1-1/4” to 1-1/2” 1-3/4” to 2-1/4” Tube OD Range (50.8 to 76.2mm) (31.75 to 38.1mm) (44.45 to 57.15mm) 100 psi (7 bar)* 80 psi (5.5bar)* 100 psi (7 bar)*... -
Page 10: Part Numbers & Diagrams
Lubricator / Filter with Gauge M5784D4 Air Hose 16.5’ M5784D6 Foot Valve M5784D2 M5784D21 M5784D2 Air Hose- 33’ Heavy-Duty M5784D8 M5784D81 M5784D82 Y-Tube for Vacuum Hose M5784D1 M5784D9 M5784D12 Air Pulsator (See Page 9) (See Page 9) Brush Soot Buster... -
Page 11: Troubleshooting Guide
2.2 Turn off air supply. Switch on air supply sharply as you pull back the pulsator. The pulsator stops vibrating in the tube. Turn off and unscrew pulsator from hose. Squirt in plenty of oil. Reconnect and turn on air supply. Soot Buster... -
Page 12: General Tips
3. Lubrication is critical. One drop per second is recommended, slightly more for the first hour of operation. 4. Clean the air pulsator after use. Wash using a clean oil and then dip in Shell Ensis Oil L or equivalent positive rust preventing oil. Soot Buster... -
Page 13: Warranty
OBLIGATIONS, CLAIMS FOR LIABILITIES, RIGHTS AND REMEDIES, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTY FOR MERCHANTABILITY AND FITNESS FOR PURPOSE. Seller’s total liability is limited to the lower of the cost of repair or replacement. Soot Buster... - Page 14 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Locally Supported By: Contact us or your local support. Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 www.elliott-tool.com/support Phone: +1 937 253 6133 • +1 800 332 0447 Fax: +1 937 253 9189 www.elliott-tool.com...
