Rupes HB 525 Operating And Maintenance Instructions Manual

Pat multifunctional swing arm

Advertisement

Quick Links

HB 525 - HB625
PAT
Multifunctional swing arm
OPERATING AND MAINTENANCE INSTRUCTIONS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HB 525 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rupes HB 525

  • Page 1 HB 525 - HB625 Multifunctional swing arm OPERATING AND MAINTENANCE INSTRUCTIONS...
  • Page 2: Safety Standards

    INTRODUCTION These instructions provide the necessary information concerning the installation, operation and proper maintenance of the arm. The user should read the manual each time before installing and starting to operate the device. The arm has been designed for professional use, and thus it should be used in this way. Use the device for extracting dry dust only.
  • Page 3: Arm Installation

    ATTENTION Maintain the arm well. Always keep it in ideal condition and clean. Strictly follow the instructions on the safe use of the arm. Any possible repairs should be carried out in service centres, using original spare parts only. Failure to follow these rules may result in serious damage. THE UNIT SPECIFICATIONS Length: 5 m –...
  • Page 4 From the point selected for the arm installation, draw a perpendicular line using a plumb line. Start from a height of 4.6 m. This line corresponds to the CENTRE of the arm wall anchoring yoke. ALL SUBSEQUENT DIMENSIONS WILL RELATE TO THIS LINE. INSTALLATION OF ARM ANCHORING YOKE At a height of 2.5 m from the ground, move 50 mm to the right from the CENTRE and mark the first hole there (Fig.
  • Page 5: Electric Connections

    ELECTRIC CONNECTIONS The arm is equipped with the following cables: One 3 x 2.5 mm cable, which supplies two 16 A sockets (item 1), marked by red tape. One 3 x 2.5 mm cable, which supplies one 16 A socket (item 2). One 4 x 1.5 mm cable, connected to the MAN-0-AUT switch.
  • Page 6 ELECTRIC AND PNEUMATIC CONNECTIONS DIAGRAM [str.6] WIRING DIAGRAM [str.8] PNEUMATIC CONNECTIONS DIAGRAM [str.10] WIRING DIAGRAM (WITH AUTOMATIC PNEUMATIC CONTROLLER) [str.11] WIRING DIAGRAM [str.13] PNEUMATIC CONNECTIONS DIAGRAM [str.14]...
  • Page 7: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS 1. NTS Sp. z o.o. [Ltd.] - the exclusive representative of RUPES s.p.a. in the Republic of Poland guarantees the highest quality and correct working of the machine operated in compliance with its operating instructions. 2. The Buyer obtains a 12-month warranty starting from the date the machine was purchased. This period will be extended by the number of days the machine is kept in the warranty repair service.
  • Page 8 NOTES...
  • Page 9 Poland, 05-083 Zaborów tel.: (022) 752 06 00 e-mail: nts@nts.com.pl Borzęcin DuŜy ul. Warszawska 749 fax: (022) 752 05 92 http://www.nts.com.pl...

This manual is also suitable for:

Hb 625

Table of Contents
