Summary of Contents for Serveredge DB Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Universal Furniture Rack DB Series DB-12RU-56FS-XX2014...
-
Page 2: Installation Instructions
DB Series Installation Instructions TOOLS REQUIRED FOR INSTALLATION PARTS C (1) Rack Top B (1) D (1) A (1) Right side panel Rack Bottom Left side panel H (1) G (1) F (2) E (4) Cable entry Panel fits fan kit... - Page 3 DB Series Installation Instructions ASSEMBLY STEP 1: STEP 2: (Q) x6 (N) x2 (W) x4 (Q) x6 (E) x4 ( J) x16 (N) x2 1. Screw 6 connecting bolts (Q) into each side panel (A and B). 1. Use 16-M6x12 hex washer screws (J) to secure two rack 2.
- Page 4 DB Series Installation Instructions ASSEMBLY STEP 5: STEP 6: (K) x4 (V) x4 (K) x4 ( J) x16 1. Use 16-M6x12 hex washer screws (J) to secure 4 caster (V) 1. Use 8-M5x12 truss screws (K) to secure panel fits fan kit (G) &...
