TECHNICAL DRAWING
INSTRUCTIONS
1
a)
Insert the hub on the pole or arm and tighten the two side screws maintaining it (Fig. 1).
b)
Insert the main body into the hub and tighten the two side screws (Fig.2).
c)
To choose the desired angle between 0°, 5°, 10°, or 15°, insert the supplied pin into one of the four
slots (Fig. 3).
Spear Lighting Ltd, Unit 8 Cowley Mill Trading Estate, Longbridge Way, Uxbridge, Middlesex, UB8 2YG
2
Tel: 01895 746006 E-Mail:
info@spearlighting.com
CLUB LED INSTALLATION INSTRUCTIONS
Power (W)
32
64
96
128
160
192
3
www.spearlighting.com
Weight (kg)
9.85
10.25
10.65
10.68
10.71
10.74
