TECHNICAL DESCRIPTION & CABLING
SUMMARY
MERCURA Développement
Customer Services
Rue Louis PASTEUR
ZA Les Gailletrous
41260 La Chaussée Saint Victor
FRANCE
tel :(33) 02 54 57 52 52
Fax :(33) 02 54 56 80 00
Email :serviceclients@mercura.fr
SIREN FLASH MODULE
1-DESCRIPTION
2-DIMENSIONS
3-COMPATIBLE LOUD-SPEAKERS
4-SIREN / LOUD-SPEAKER CONNECTION
5- WIRING
6-RECOMMENDED CABLING INSTRUCTIONS
Customer Services
PRIX D'UN APPEL LOCAL
Mondays to Fridays - 8.00am to 12.00pm and 1.00pm to 5.00pm
0810 57 52 52
1-5
Advertisement
Table of Contents
Summary of Contents for Mercura SIREN FLASH MODULE
- Page 1 TECHNICAL DESCRIPTION & CABLING SIREN FLASH MODULE SUMMARY 1-DESCRIPTION 2-DIMENSIONS 3-COMPATIBLE LOUD-SPEAKERS 4-SIREN / LOUD-SPEAKER CONNECTION 5- WIRING 6-RECOMMENDED CABLING INSTRUCTIONS MERCURA Développement Customer Services Rue Louis PASTEUR ZA Les Gailletrous 41260 La Chaussée Saint Victor FRANCE Customer Services tel :(33) 02 54 57 52 52...
- Page 2 1- DESCRIPTION The siren is equipped with two wired waterproof connectors : - Black 2 pin connector for connection to loud-speaker. - Grey 3 pin connector for power supply connection (12 - 24 volts), and 1 input to change to Night mode (by connection to the earth/ground) enabling the reduction of the volume level (Not available with certain siren tones Note : The siren module is fully resin-coated...
- Page 3 LOUD-SPEAKER WITH NOZZLE 2.1 Kg 150W LOUD-SPEAKER 2.6Kg NOTE: The siren flash module is designed and approved for functioning with one of the five loud-speakers described Above. The power obtained varies according to the loud-speaker model chosen. SIREN/LOUD-SPEAKER CONNECTION 3 x power supply cables connected...
-
Page 4: Wiring Diagram
The siren is activated once it is connected to the power supply 5-WIRING DIAGRAM Siren Day/night Siren Module FLECHE HAUTE PORTE LAT. ALARME BAT. Control PUIS. M A D E I N F R A N C E MERCURA Power Panel Module Power supply . Battery Loud-speaker... - Page 5 6-INSTALLATION INSTRUCTIONS ECCES products must be fitted with care due to the ergonomics of their use Mercura cannot be held responsible for damage or failure resulting from accessories or equipment inappropriately connected to their power supply. BATTERY CONNECTION AND PROTECTION - Adapt the cabling diametre to the power supply.
