Summary of Contents for Jupiter AJ120
- Page 1 User Manual...
- Page 2 Product Story Specially designed for RGB enthusiasts who desire superior performance from their case fans. The Jupiter AJ120 fans feature seven blades, sleeve bearings with a long lifespan, ARGB LEDs with 16.8 million color options and a one-click RGB Controller.
-
Page 3: Package Contents
Package Contents Triple Pack 1. Jupiter AJ120 Fans x 3 2. Addressable RGB Controller x 1 3. Screws x 12 4. 3-Pin Headers x 3 Single Pack 1. Jupiter AJ120 Fan x 1 2. Screws x 4 3. 3-Pin Header x 1... -
Page 4: Specifications
Specifications 120mm 25mm Product Name Jupiter AJ120 Single Pack IW-FN-AJ120-1PK Model Number Triple Pack IW-FN-AJ120-3PK Fan Size 120 x 120 x 25mm Material PBT, PC Rated Voltage DC 12V Rated Power 2.4W Rated Current 0.20A ADD RGB Rated Voltage DC 5V ADD RGB Rated Power 1.1W... -
Page 5: Cable Information
Cable Information Triple Pack Addressable RGB Y-Cable Addressable RGB Fan Cable Addressable RGB Controller Single Pack Addressable RGB Y-Cable Addressable RGB Fan Cable... -
Page 6: Installation
Installation Please make sure the power is off. Installation Video Install the fans in your PC case and mount them in the designated areas. The fan cable, Addressable RGB Y-Cable and their counterparts are attached to each fan. Please connect as followed: Connect the fan’s Addressable RGB Y-Cable to a motherboard’s 3-pin addressable RGB header. - Page 7 Installation If your motherboard does not support an addressable header, please use the included Addressable RGB Controller to connect to your PSU’s SATA cable and the fan’s Addressable RGB Y-Cable in order to use the 11 different lighting effects. (Only in Triple Pack) PSU’s SATA cable...
-
Page 8: Troubleshooting
Troubleshooting If your fan does not operate properly, please follow the instructions below: 1. Please check your system’s power. 2. Please make sure all the connectors are connected properly. Important Notes 1. Please install the fans by following our instructions. 2. - Page 9 Copyright © 2020 In Win Development Inc. All Rights Reserved.
