- Page 1 SEFRAM 9822-9822B Data Logger Hygro-thermometer Instruction Manual Tel : 04 77 59 01 01 32, rue Edouard Martel Fax : 04 77 57 23 23 BP55 F42009 – Saint Étienne Cedex 2 Web : www.sefram.fr E-mail: sales@sefram.fr...
-
Page 2: Table Of Contents
Data Logger Hygro-thermometer CONTENTS TITLE PAGE 1. General Description….…………………………………………………….……………..1 2. Safety Information………………………………………………………………………... 1 3. Features…………………………………………………………………………………….1 4. Specifications……………………………………………………………………………... 2 5. Symbol Definition & Button Location…………............3 6. Button Instructions ………………………….…………………........5 6.1 Power ON/OFF Button……………………………………........5 6.2 Backlight Button…………………...............5 6.3 Data-Hold Button………..................5 6.4 REC Button…..…………………................5 6.5 MEM Button…..………………….................5 6.6 RECALL Saved Reading Button……………………..........5 6.7 MAX/MIN/AVG Button…………………...............6... -
Page 3: General Description
Data Logger Hygro-thermometer 1. GENERAL DESCRIPTION Thank you for choosing our Data Logger Hygro Thermometer. To ensure the safety and the best performance of this instrument, we recommend you to read and follow the manual carefully before operation. Data can be stored in the meter or directly saved on a computer through PC interface. Recorded data can be further processed on a computer. -
Page 4: Specifications
Data Logger Hygro-thermometer 4. SPECIFICATIONS 4-1 Probe: RP-33 Sensor type: Semi-Conductor humidity and temperature sensor Relative humidity range: 0 to 100%RH Temperature range: -20°C to 60°C (-4°F to 140°F) (253K to 333K) Dew point temperature range: -50°C to 60°C (-58°F to 140°F) (223K to 333K) Wet bulb temperature range: -20°C to 60°C (-4°F to 140°F) (253K to 333K) Resolution: 0.1%RH, 0.1°C, 0.1°F, 0.1K Accuracy: [at 23°C(73.4°F)]... -
Page 5: Symbol Definition & Button Location
Data Logger Hygro-thermometer Storage temperature: -20°C to 60°C (-4°F to 140°F) Storage humidity: 10 to 75%RH Dimensions/ Weight: Meter: 187mm(L) × 75mm(W) × 29mm(H) / Approx. 330g Probe(RP-33): 16mm Diameter x 98mm(L) Standard Accessories: Instruction manual, battery 1.5V AAA x 4 pcs, Windows software, micro USB cable, K type bead probe, carrying case. - Page 6 Data Logger Hygro-thermometer ○ , ○ , Sensor Probe RECALL Saved Reading Button ○ , ○ , Thermocouple Input MEM Button (Set 100 Memory) ○ , ○ , Display Screen SETUP Button ○ , ○ , Power ON/OFF Button USB Interface ○...
-
Page 7: Button Instructions
Data Logger Hygro-thermometer 6. BUTTON INSTRUCTIONS 6.1 Power ON/OFF Button: Press the button to turn on the meter. Press and hold button for 3 seconds to turn off. 6.2 Backlight Button: Press to turn on the LCD backlight. This makes it easier to read in dark environment. Press again to turn off backlight. -
Page 8: Max/Min/Avg Button
Data Logger Hygro-thermometer 6.7 MAX/MIN/AVG Button: Under this mode, the unit simultaneously monitors and stores the maximum, minimum and average value in the memory. The unit will keep updating/refreshing the data. To start: button. “ ” symbol lights up on LCD, the reading shows the maximum data. (1) Press button again to show minimum data;... -
Page 9: Menu Item
Data Logger Hygro-thermometer 7.2 Menu Item: Fig.1 Set Bluetooth ON/OFF. Fig.2 Set thermocouple type. Fig.3 Set Unit. Fig.4 Set interval time for data logging. Fig.5 Set offset to compensate for probe errors. -
Page 10: Menu Description
Data Logger Hygro-thermometer Fig.6 Set alarm point. Fig.7 Set auto power off time. Fig.8 Set system clock. 7.3 Menu Description: 7.3.1 Set Bluetooth ON/OFF Press the button to turn on or off. (see Fig.9 or Fig.10) Fig.9 Fig.10 Note: When Bluetooth function is turned ON, it is entering standby/pairing mode, the blue LED built in flashes once every 3 seconds. -
Page 11: Select Thermocouple Type
Data Logger Hygro-thermometer 7.3.2 Select Thermocouple Type: K, J, E, T, N, R or S Press the button to select thermocouple type. (see Fig.11) 7.3.3 Set Unit: Fig.11 (1) Press the button to select °C、°F、K. 7.3.4 Setting Interval Time For Data Storing: (1) Press the button to set minute or second. -
Page 12: Set Auto Power Off Time
Data Logger Hygro-thermometer (2) When setting on mode, press the button to set Hi and Lo limit. ( RH alarm setting see Fig.16 and Fig.17 ) ( T1 alarm setting see Fig.18 and Fig.19 ) ( T2 alarm setting see Fig.20 and Fig.21 ) Note: When measuring value over alarm point, the symbol will blink “... -
Page 13: Clearing Data Logger Records
Data Logger Hygro-thermometer 7.4 Clearing Data Logger Records: (1) Turn off the unit. (2) Press and hold button and then press power button to turn on the unit. SUrE 5, " and “ (3) Keep holding button, then LCD will show " ", "... -
Page 14: Bluetooth Adapter Installation
Data Logger Hygro-thermometer 8.2 Bluetooth Adapter Installation: (1) Power off (2) Open the cover of the Bluetooth cabinet by a screwdriver. (3) Install the Bluetooth adapter into its compartment, push up the adapter to the connector. Close the Bluetooth cabinet cover and fasten the screw. 9. -
Page 15: Testlink Se-522 Software
Data Logger Hygro-thermometer 11. Testlink SE-522 SOFTWARE 11.1 The SE-522 package contains: Software CD disk Micro USB cable 11.2 System Required: Windows XP/ VISTA/ Windows 7/ Windows 8/ Windows 10 11.3 Minimum Hardware Required: PC or laptop with CD-ROM drive. ... - Page 16 Data Logger Hygro-thermometer 11.5 How to save the recorded real time data to a file? (1) Click the graph window you want to save and the graph window will become active, then choose File | Save from main menu or click from the tool bar . an active window not active window (2) There will be a save dialog window for you to choose the file name and file type to save.
- Page 17 Data Logger Hygro-thermometer 11.6 How to load the recorded data from the memory of Hygro Thermometer and save it to a file? (1) Power on the Hygro Thermometer. (2) Press the “ REC ” button of the meter to start recording data. (3) After a while, press “...
- Page 18 Data Logger Hygro-thermometer DataLogger: By opening the DataLogger Window, the user can load recorded data of meter to PC in this window. Output To Graph - Graphing tabular data. Com port of Bluetooth device – Choose com port to connect to Bluetooth device. Search Bluetooth Device Automatically searching and connecting to Bluetooth device.
- Page 19 Data Logger Hygro-thermometer for examples: It will transfer first data set to graph on the right hand side. The user can also click at any other data set to choose that set for graph. Graph: Tool Bar Statistic 1 Statistic 2 Tool Bar: - Display or hide Statistic1.
- Page 20 Data Logger Hygro-thermometer - Normal cursor. - When selected, the mouse cursor will become a cross sign when moving to the graph, click on the graph to mark a cross sign on the graph. And all the mark you make will exist with T1.
- Page 21 Data Logger Hygro-thermometer 11.9 Frequently Asked Question: (1) How to uninstall SE522 ? Answer: Uninstall SE522 by launching the Add/Remove Programs applet out of the Control Panel, highlighting the SE522, and clicking on the Add/Remove... push button, then it will remove the SE522 folder and files from your computer.
- Page 22 Data Logger Hygro-thermometer 11.10 Bluetooth Pairing: 11.10.1 Via ACTION CENTER (Windows 10) (1) Open [ ACTION CENTER ]; (2) Click [ All Settings ]; (3) Click [ Devices ]; (4) Select [ Bluetooth ]; (5) Turn On; (6) Select [ BT-xxxxxx ](serial number); (7) Click [ Pair ];...
- Page 23 Data Logger Hygro-thermometer 11.10.2 Via Contro Panel (1) Click [ START ] and then click [ Devices and Printers ]; (2) Click [ Add a device ]; (3) Choose BT-XXXXX Bluetooth Adapter , then click [ Next ].
- Page 24 Data Logger Hygro-thermometer (4) To find out which COM port has been allocated to the meter, click on the Windows Start button and search for “Bluetooth” and choose “Change Bluetooth settings” (5) Click on the “COM Ports” tab to see which port has been allocated to the meter.
