Health Craft SP-SI Installation Instructions Manual

SuperPole™ with Safety Island™
A unique circular ring with a tray that mounts at any height to the
SuperPole™. Combines the fixed support benefits of a grab bar with the
simplicity and convenience of a tray.
Features and Benefits
360 Degree Support – Effective ring design provides continuous support 360 Degree Support
to make small, safe steps, reducing unnecessary reaching and twisting.
Ring & tray will not spin freely around the pole, providing fixed support
and an ideal weight bearing surface when gripping strength is weak.
Convenient Convenient – Easy to clean tray can be accessed from around the
SuperPole™. Perfect for reading material, medication or items needed
within arms reach. The Safety Island™ will mount to the SuperPole™ at
virtually any height.
Ideal for Kitchens – Install in the center of the kitchen to create secure Ideal for Kitchens
support when moving between chair, table, sink or counter. Use the tray
to place meals while moving from cooking surface to kitchen table.
Bedroom
HealthCraft Products Inc., 2790 Fenton Road, Ottawa, Ontario, Canada K1T 3T7
Toll Free: (888) 619-9992 Tel: (613) 822-1885
Web: www.healthcraftproducts.com
H H
Bathroom Hospital
Technical Specifications:
Tubular Ring
Tray
Floor to Ceiling Range
Uni-Fit Extender™
™
SuperPole Ultra
™
Ceiling Plate Extender
Pole Material
Grip Material
Expansion Mechanism
Weight Capacity
Assistance Level
Fax: (613) 822-1886
E-mail: info@healthcraftproducts.com
Typically 28-38"/71-97cm from floor, 18"/46cm diameter, 1.25"/3.175cm diameter
tube for easy gripping.
14"/36cm diameter A.B.S. tray, easy to wipe clean. Weight capacity 15lbs/7kg.
93-99"/236-251cm (standard).
Increase floor to ceiling range to 100-120"/254-305cm. Sold separately. NOT TO
BE USED WITH SUPERTRAPEZE™.
NOT TO BE USED WITH SAFETY ISLAND™.
Allows standard ceiling plate (20"/51cm length) to span 30"/76cm with holes for
ceiling attachment to 24"/61cm ceiling beam centers. Sold separately.
Heavy gauge steel, 1.5"/3.81cm diameter. High temperature baked powder coat
gloss white enamel.
Grey, premium high quality grip, 20"/51 cm long. Does not contain natural dried
rubber or latex. Washable.
Steel jackscrew, zinc plated, 1-1/8" fine cut thread.
250lbs/113kg. Bariatric model 450lbs/205kg capacity.
M ASSISTANCE LEVEL M
I A
1 2 3 4
N X
