Summary of Contents for CMX LED 8245

  • Page 2: Table Of Contents

    Contents Warning………………………………………………………..2 Caution ……………………………………..…………………3 Main unit Description…………………….………...………...5 Control Panel Button Function ……………….………………5 Front Panel …………………………………………..………..5 TV Terminal Connections …………………………………….6 Remote control……………………………………..………….7 OSD Menu Operation…………………………….……………….9 Main Menu………………………………………...………………9 Other Menu……………………………………………………….23 Multimedia ……………………………..…..…………………25 Personal Video Recorder (PVR)………………...………………..30 Specification ………………………………….…………………..36...

  • Page 3: Warning

    Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to avoid the risk of electric shock, do not disassemble this equipment by anyone except a qualified service personnel.

  • Page 4: Caution

    Caution Caution High voltages are used in the operation of this product. Do not open the product's casing. Refer servicing to qualified service personnel . Caution To prevent fire or electrical shock hazard, Do not expose the main unit to moisture. Caution Do not drop or push objects into the television cabinet slots or openings.
  • Page 5 Caution Caution Never stand on, lean on, push suddenly the product or its stand. You should Pay special attention to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual, and damage to the television, may result if it should fall.

  • Page 6: Main Unit Description

    Main unit Description Control Panel Button Function POWER: ON/OFF button SOURCE: Select signal input. MENU: Main Menu display and menu selection. CH-: Channel down CH+: Channel up VOL-: Volume down VOL+: Volume up Front Panel Power/Standby Indicator: Green and red dual-color LED. It shows red when the TV is turned off and green when turned on.

  • Page 7: Tv Terminal Connections

    TV Terminal Connections RF input terminal. Audio input terminal. CVBS input terminal. Mini YPbPr input terminal. Earphone output terminal. Coaxial Audio output terminal VGA input terminal. PC Audio input terminal . SCART input terminal. HDMI2 input terminal. HDMI1 input terminal. USB input terminal...

  • Page 8: Remote Control

    Remote control POWER: Turn the TV on or off. MUTE: Press to mute the sound. Press again to regain the sound. 0-9: Press 0~9 to select a TV channel directly The channel will change after 2 seconds. Applicable for entering page number in teletext mode and so on.
  • Page 9 TEXT: Press to turn the Teletext On and Off INDEX: Press to return to the index/initial page. MIX :Press to display the picture and the teletext at the same time REVEAL: Reveal or Hide the hidden words. HOLD : HOLD On or Off for current page display . SUBPAGE : Display a sub-page of upper options SIZE : Change the size of display in Teletext mode.

  • Page 10: Osd Menu Operation

    OSD Menu Operation 1. Main Menu Main Menu items （from right order CHANNEL –> PICTURE -> SOUND -> TIME -> OPTION -> LOCK ） at DTV/ATV input source，the first page showed is CHANNEL。At non DTV/ATV input source，the first page is PICTURE as default。 Currently press ENTER to get in sub menu，submenu is Highlight fixed on，press button key，the subtopic turns up with full screen.
  • Page 11 When ATV tuning, you can press menu to skip ATV tuning and start DTV tuning. 1.1.2 DTV manual tuning: Press enter to confirm tuning（only in DTV condition） 。 1.1.3 ATV manual tuning: 1 )function description： Item Adjust item Description...
  • Page 12 Storage To 1 – 100 Current storage space shows Default option depends on country System BG -> I -> DK -> L selection Current CH 1 – 100 Current channel shows Search Can be searched at full channel condition Fine-Tune Fine-tune When gray ，...
  • Page 13 MENU： exit DELETE to enter normal condition EXIT： exit menu； ：cancel current channel, and turn back to normal Modify current channel name, only used in ATV mode. Operation instruction： 1) at normal condition, press to enter RENAME； 2) at RENAME mode,： (RENAME) MENU：exit RENAME mode，back to normal.
  • Page 14 1.1.5 Signal Information: It only make use at DTV condition, shows signal information, includes：channel /network /modulation /quality /strength. 1.1.6 Recorded Mode Enter Recorder menu, do reservation of recording, check PVR specification in details. 1.2 PICTURE 1.2.1 Picture Mode 1 )function instruction： Item Adust range description...
  • Page 15 1.2.2 Contrast / Brightness / Color / Sharpness operation instruction： Adjust :LEFT,RIGHT to adjust numeric size； Menu :press MENU to return picture main menu； Exit :EXIT to exit menu； UP,DOWN: adjust content with up/down key: as Contrast / Brightness / Color / Sharpness；...
  • Page 16 Operation instruction： enter into the menu, choose with UP,DOWN：off /low /middle /default。 1.3 SOUND 1.3.1 Sound mode Operation instruction： Adjust :LEFT,RIGHT adjustable： Standard -> Music -> Movie -> Sports -> User； Menu :MENU to return picture main menu； Exit :EXIT to exit menu； 1.3.2 Treble/ Bass /Balance Operation instruction：...
  • Page 17 1.3.3 Auto Volume 1）Function：auto sound adjust 2）operation：ENTER to set ON/OFF 1.3.4 Surround sound 1）function：surround settings 2）operation：ENTER to set ON/OFF 1.3.5 SPDIF 1）function: SPDIF settings 2）operation： Enter second menu, choose different mode with UP,DOWN: Off/PCM/Auto. TIME 1.4.1 Clock 1) function instruction： The default rate isn’t get the time information from DTV, but I can set it by hand when enter CLOCK menu.
  • Page 18 1.4.2 Off time Operation instruction： Move :UP,DOWN ; Menu :MENU to back picture main menu； Exit :EXIT； LEFT,RIGHT key to set parameter; 1.4.3 On time Operation instruction： Move :UP,DOWN ; Menu :MENU to back picture main menu； Exit :EXIT； LEFT,RIGHT key to set parameter; 1.4.4 Sleep time 1）function instruction：...
  • Page 19 1.5 OPTION 1.5.1 OSD Language Operation instruction： Enter second menu, use UP, DOWN to set language 1.5.2 Audio Language 1st 1） function instruction： Items Adjust item description First language Audio Language 1st Not selected at non DTV condition selected 2） Operation instruction： Enter second menu, use UP,DOWN to set language;...
  • Page 20 1.5.4 Subtitle Language 1st 1）function instruction： Items Adjust item description Subtitle Language 1st First language Not selected at non DTV condition selected 2） Operation instruction： Enter second menu, use UP,DOWN to set language; 1.5.5 Subtitle Language 2nd 1）function instruction： Items Adjust item description Subtitle Language 2nd...
  • Page 21 1.6 LOCK 1.6.1 Lock Channel Operation instruction： LEFT to quit passport，turn back main menu； RIGHT to delete passport wrote and rewrite correct one. It need input correct passport to enter the LOCK submenu. It shows Wrong password it uncorrect passport； MENU to exit to LOCK menu；...
  • Page 22 Enter the submenu, set new password and Set Password confirm it 2）Operation instruction： LEFT to exit reset password, back to main menu； RIGHT to cancel the written password, and then rewrite it. If the password get wrong twice, it shows“password doesn’t match”。 1.6.3 Block Program 1）...
  • Page 23 2）Operation instruction： Enter second menu, use UP，DOWN key to choose data，press ENTER to confirm it。 1.6.5 Hotel Setting Items Adjust item description Enter to set On/Off. Hotel Lock On, Off Available when turn on the Hotel Lock Lock Channel On, Off Off, DTV, Radio, Press ◄/►...

  • Page 24: Other Menu

    2. Other menu 2.1 Input Source Key instruction： Input Source format，mainly with UP/DOWN to choose object. And then choose related function key to do the other action. Select: select current item； Exit: exit current item； ENTER: confirm ； 2.2 Favorite List Favorite List and Channel List is of the same settings, but showed as clients favorite channel in Program edit.，use FAV key to show and close Favorite List menu.
  • Page 25 Can choose down ： Details Channel information selected programme information ； if programme classified by time, shows programme information currently time 1） operation notes： Move: move up and down. EXIT：exit EPG. ENTER: switch to current selected programme ； Index: switch to type option. Record: record programme.

  • Page 26: Multimedia

    3. Multimedia 3.1 brief introduction At Input Source menu, choose USB port to enter Multimedia. 3.2 PHOTO 1) multimedia main menu style： Discs multimedia operation operation instruction： When choose picture, it shows picture preview frame and details, then press ENTER to enter full screen picture playing. When after picture full playing, press ENTER to show the following operation key.
  • Page 27 Show current picture preview, the information is showed as follows: Blue Hills. jpg ----files name； Info/Display [Resolution] 1024 x 768 ----resolution； [Size] 28521 Bytes ----pic size； Exit Exit playing，enter previous menu, focus to the multimedia menu PHOTO； Full screen playing of PHOTO，if several files need to play, it would switch Play automatically after some time.( default as 5 second) Pause...
  • Page 28 3.4 MUSIC 1） MUSIC playing condition and keys function MUSIC playing is the menu just like playing software in PC, mainly have Playlist、 basic information, processing sign, operation guide part, as follows: Songs name Songs infor Songs list MUSIC image Operation guide Play time progress bar...
  • Page 29 2） key function Function Enter Play Focus files, if Focus is current file, it play from the beginning. Up/Down Move Focus at songs list Exit MUSIC playing menu, but keep playing songs, when exit to Browser Exit menu, Focus the current playing files. Play Play ；...
  • Page 30 clients can browse the list with up down key, and to select files by enter key; then press list or no operation for 10 seconds, it would exit. MOVIE information, includes: current film’s file name, film’s Info：Show the current resolution, film’s frequency, film’s total time and playing time. Goto: it pop out the frame as：00:00:00/01:23:45，the first time is what clients input, clients can switch the position with left right key, you can also switch the number with up down key, and press enter to time settings.

  • Page 31: Personal Video Recorder (Pvr)

    4. Personal Video Recorder（PVR） 4.1PVR menu 4.1.1 PVR File System Enter PVR from CHANNEL menu, as follows: Select Disk: Choose the disc to store whatever content need record, as follows, default as C: Check PVR File System: Check storage equipment PVR File System is well established. Default as Start，Enter and Right key to inspect the USB files system and speed, the processing shows Checking…；...
  • Page 32 Time shift size When finish Creating PVR file system, It pop out Time Shift Size setting menu, and clients can set the space size for time shift 4.1.2Channel – Recorder List 1） pattern for reference The menu is as follows， Title, ordering sign...
  • Page 33 [TIME] 15:29:02 ----record starting time [DURATION] 0000:01:52 ----duration time [CHANNEL NAME] 40 BBC NEWS ----channel list [PROGRAM NAME] No Information ----programme name. 4.1.3 PVR – Record Mode 1） recorded mode Item format notes Menu title Recorder Mode Menu topic； When choose Auto, get current programme to set recording, Title shows its current name.
  • Page 34 4.1.4 PVR – Recorder Schedule Function Exit Recorder Schedule List menu，enter PVR menu ，Focus on Recorder Menu Schedule List； Move Move Focus up and down； ●(Delete) Delete Focus items； Exit Exit menu ； 4.2 PVR shortcut function 4.2.1 PVR shortcut keys under the DTV Function Record Enter Record mode；...
  • Page 35 It shows Timeshift Start condition，as follows： Function Play Enter Timeshift Play condition； Stop Stop Timeshift； Exit Exit Timeshift Close Timeshift，pop out Recorded List； List From Recorded List menu to enter Playback, and then exit Timeshift； Exit Recorded List first and then show menu Timeshift； Timeshift Play At Timeshift Play condition, the system record DTV and play it at the same time.
  • Page 36 USB FORMAT MODE MPEG4 DIVX4,DIVX5,XVID MOVIE MPEG1/2 PHOTO MUSIC Special Note： 1）Support hard disk，the maximum storage capacity is 400G 2）Folder in support of the greatest depth is 30 3）Each folder in support of the largest number of documents is a 5000 4）Only support single audio channel audio format and dual-audio channel audio format Operation Instructions PS：USB only support PHOTO, MUSIC and MOVIE.

  • Page 37: Specification

    SPECIFICATIONS MODEL LED 8245 Resolution 1920 x 1080 Contrast Ratio 800:1 Aspect Ratio 16:9 AC Input AC100-240V, 50/60HZ AMPLIFIERS 2*3W TV System PAL/SECAM HDMI PC Audio In Input SCART Audio Input CVBS Mini YPbPr Earphone Output Coaxial ≤50W POWER CONSUMPTION...
