- Page 1 Shower Thermostatic Mixer Fitting Instructions...
- Page 2 Thank you for selecting this product. We have taken great care to ensure that this product reaches you in perfect condition. However should any parts be damaged or missing, please contact the retailer from where the product was purchased referencing the product description.
- Page 3 Installation Notices Safety Notice: Prior to drilling into walls, check there are no hidden electrical wires, cables or water supply pipes. Always wear protective equipment such as safety glasses and hearing protection whilst using power tools. Tools for installation （not supplied) Electric drill PTFE Tape Spirit Level...
- Page 4 Component Listing No. Name Shower Body Vertical Pipe Horizontal Pipe Shower Head Shower Handset Shower Handset Holder Shower Hose Instructions Pipe Bracket 10 Pipe Couplers 11 Easy Fix Kit Wall Plate Olive Union Cover Plate Filler *Important note: - Screws and wall plugs provided are for solid wall types only.
- Page 5 Technical Drawings Ø 200 Ø 22 Ø 120...
-
Page 6: Installation Procedure
Installation Procedure Easy Fix Kit (11) 150±0.2 Pipe Couple’s (10) cold water water 1. Pipe work centers should measure 150mm in distance 2. For your benefit we have included two types of and ≥ 25mm of protrusion from the wall to aid fitment. fittings with this shower- you only need to choose the one that best fits your particular installation. - Page 7 5. Attach the pipe and mark the desired location for the 6. Remove the pipe and secure pipe bracket(9) into the horizontal pipe bracket (9). position previous marked using the screws provided. 7. Attach the pipe on to the shower body (ensuring the 8.
- Page 8 Product Operation and Maintenance 1. Turning the left handle of the shower, controls the flow rate and turning the handle anti-clockwise will increase the flow to the m a i n s h o w e r h e a d . Tu r n i n g t h e h a n d l e clockwise will increase the water flow rate to the shower handset.
