User Manual

Art.Nr.: led53000

Speciﬁcations

Änderungen sind ohne Ankündigung möglich.

Changes are possible without prior notice.

Rev. 2018-26-31

Control

Table of Contents

Chapters

Summary of Contents for Focon Showtechnic EXPOLITE Retron LED 575

Page 1 Retron LED 575 Bedienungsanleitung User Manual Art.Nr.: led53000 Speciﬁcations Eigenschaften Menu Bedienelemente Control Steuerung Bedienungsanleitung bitte aufbewahren Änderungen sind ohne Ankündigung möglich. Changes are possible without prior notice. Keep this Manual for later queries Rev. 2018-26-31...
Page 2 Lesen Sie diese sorgfältig, bevor Sie das Gerät in Betrieb nehmen. The enclosed General Information for Expolite Units are part of these user manual. Read them carefully before operating the device. FOCON SHOWTECHNIC Vertriebsgesellschaft mbH Teichweg 4+6 D-49504 Lotte/Wersen Telefon: ++49 (0) 541-77095-0...
Page 3: Table Of Contents
Inhalt - Content Inhalt - Content Seite / Page Lieferumfang D-04 Technische Daten D-05 Abmessungen D-06 Installation D-07 Bedienung D-08 Steuerung mit DMX512 D-11 Delivery E-26 Product Information E-27 Dimensions E-28 Installation E-29 Operation E-30 Using DMX512 Controller E-33...
Page 4 Lieferumfang - Expolite Retron LED 575 - Anschlusskabel für Spannungsversorgung - Bedienhinweise für Expolite Geräte - Bedienungsanleitung Expolite Geräte werden vor dem Versand sorgfältig geprüft. Sollte der Lieferumfang dennoch nicht vollständig sein, wenden Sie sich bitte umgehend an Ihren Vertriebspartner.
Page 5: Technische Daten
Technische Daten Spannungsversorgung 100V - 240V AC 50/60Hz Maximale Leistungsaufnahme 400W Abmessungen 462 x 271 x 493 mm Gewicht 8 kg Anschlüsse Power In/Out | DMX In/Out Betriebstemperatur -20°C - 45°C Luftfeuchtigkeit < 98% Schutzklasse IP 20 Gehäuse beschichtetes Metall LEDs 462 x OSRAM (192 x RGB LEDs Außenring, 144 x RGB LEDs Innenring, 108 x WW LEDs + 18 x...
Page 6: Abmessungen
Abmessungen D-06...
Page 7: Installation
Installation Montage Hängend Das Gerät hat eine 12,5mm Bohrung im Bügel zum Anbringen von Schellen und Zapfen bis M12. Geräte müssen entsprechend der jeweils gültigen Vorschriften sicher montiert und mit einer zweiten Sicherung gegen herabfallen versehen werden. Hierzu ist am Gerät eine Öse für Safeties angebracht.
Page 8: Bedienung
Bedienung Bedienelemente am Gerät Menüstruktur MENU Address 0 - 255 Conﬁg Mode Channel Mode 16Ch 51Ch 55Ch 64Ch Disable Keep Screen On Enable Keep DMX Data Disable Enable Fast Dimmer Disable Enable Temperature System Info Load Default TRUE FALSE LED All On LED all on Auto Mode Speed Auto Test Speed...
Page 9 DMX-Adresse einstellen MENU Address 0 - 255 Im Menü wird im Punkt ADDRESS die DMX-Startadresse des Gerätes eingestellt. Diese bleibt auch bei dem Wechsel des Channel Modes erhalten. DMX-Kanalbelegung einstellen MENU Conﬁg Mode Channel Mode 16Ch 51Ch 55Ch 64Ch Im Menü wird im Punkt Conﬁg Mode, Untermenü Channel Mode die Belegung der DMX-Kanäle des Gerätes festgelegt.
Page 10 Sonstige Einstellungen MENU System Info Temperature Load Default TRUE FALSE LED All On LED all on Auto Mode Speed 0 - 255 Auto Test Speed Auto Test Auto Mode 1 Auto Mode 2 Auto Mode 3 Auto Mode 4 Auto Mode 5 Auto Mode 6 System Info\Temperature: zeigt die aktuelle Temperatur der LED-Einheit Load Default: setzt das Gerät zurück auf die Werkseinstellungen (TRUE) oder bricht den Vorgang...
Page 11: Steuerung Mit Dmx512
Steuerung mit DMX512 DMX-Kanalbelegung Dieses Gerät verfügt über verschiedene DMX-Personalities. Bei diesen werden unterschiedlich viele DMX-Kanäle belegt und die Reaktion des Gerätes unterscheidet sich entsprechend. Es sind 6 DMX-Personalities (2-/7-/16-/51-/55-/64-Kanäle) wählbar. Durch Änderungen in der Gerätesoftware kann es zu weiteren oder geänderten Funktionen kommen. Auf der Website steht das aktuellste Dokument „DMX-Channels“...
Page 12 16Ch Mode 0-255 Master 0-255 Outer Red 0-255 Outer Green 0-255 Outer Blue 0-255 Inner Red 0-255 Inner Green 0-255 Inner Blue 0-255 Center Warm White 0-255 Center Amber 0-255 Back Warm White Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167...
Page 13 0-255 Outer Green 6 0-255 Outer Blue 6 0-255 Outer Red 7 0-255 Outer Green 7 0-255 Outer Blue 7 0-255 Outer Red 8 0-255 Outer Green 8 0-255 Outer Blue 8 0-255 Inner Red 1 0-255 Inner Green 1 0-255 Inner Blue 1 0-255...
Page 14 55Ch Mode 0-255 Master Outer Strobe 0-10 No Function 11-240 Slow to fast 241-255 Random Strobe Inner Strobe 0-10 No Function 11-240 Slow to fast 241-255 Random Strobe Center Strobe 0-10 No Function 11-240 Slow to fast 241-255 Random Strobe 0-255 Outer Red 1 0-255...
Page 15 0-255 Inner Blue 2 0-255 Inner Red 3 0-255 Inner Green 3 0-255 Inner Blue 3 0-255 Inner Red 4 0-255 Inner Green 4 0-255 Inner Blue 4 0-255 Inner Red 5 0-255 Inner Green 5 0-255 Inner Blue 5 0-255 Inner Red 6 0-255...
Page 16 0-255 All LED Strobe (Slow to fast) 0-255 Outer Strobe (Slow to fast) 0-255 Inner Strobe (Slow to fast) 0-255 Center Strobe (Slow to fast) Dimmer Speed 0-254 Fast to slow Tungsten 0-255 Inner Red 1 0-255 Inner Red 2 0-255 Inner Red 3 0-255...
Page 17 0-255 Outer Green 7 0-255 Outer Green 8 0-255 Outer Blue 1 0-255 Outer Blue 2 0-255 Outer Blue 3 0-255 Outer Blue 4 0-255 Outer Blue 5 0-255 Outer Blue 6 0-255 Outer Blue 7 0-255 Outer Blue 8 D-17...
Page 18: Mode
Neue DMX-Kanalbelegung ab August 2018: 2Ch Mode 0-255 Master Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 7Ch Mode 0-255 Master 0-255 Outer Dimmer Outer Strobe 0-10 No function 11-240 Slow to fast 241-255...
Page 19: Mode
16Ch Mode 0-255 Master 0-255 All LED Strobe (slow to fast) Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 Dimmer Speed 0-254 Fast to slow Tungsten Effect 0-255 Outer Red 0-255 Outer Green...
Page 20: Outer Red
51Ch Mode 0-255 Outer Red 1 0-255 Outer Green 1 0-255 Outer Blue 1 0-255 Outer Red 2 0-255 Outer Green 2 0-255 Outer Blue 2 0-255 Outer Red 3 0-255 Outer Green 3 0-255 Outer Blue 3 0-255 Outer Red 4 0-255 Outer Green 4 0-255...
Page 21: Inner Red
0-255 Inner Blue 4 0-255 Inner Red 5 0-255 Inner Green 5 0-255 Inner Blue 5 0-255 Inner Red 6 0-255 Inner Green 6 0-255 Inner Blue 6 0-255 Inner Red 7 0-255 Inner Green 7 0-255 Inner Blue 7 0-255 Inner Red 8 0-255...
Page 22: Outer Green
55Ch Mode 0-255 Master 0-255 Outer Red 1 0-255 Outer Green 1 0-255 Outer Blue 1 0-255 Outer Red 2 0-255 Outer Green 2 0-255 Outer Blue 2 0-255 Outer Red 3 0-255 Outer Green 3 0-255 Outer Blue 3 0-255 Outer Red 4 0-255...
Page 23: Inner Red
0-255 Inner Blue 2 0-255 Inner Red 3 0-255 Inner Green 3 0-255 Inner Blue 3 0-255 Inner Red 4 0-255 Inner Green 4 0-255 Inner Blue 4 0-255 Inner Red 5 0-255 Inner Green 5 0-255 Inner Blue 5 0-255 Inner Red 6 0-255...
Page 24: Outer Green
64Ch Mode 0-255 Master 0-255 All LED Strobe (Slow to fast) Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 Dimmer Speed 0-254 Fast to slow Tungsten Effect 0-255 Outer Red 0-255 Outer Green...
Page 25: Outer Red
0-255 Outer Green 4 0-255 Outer Blue 4 0-255 Outer Red 5 0-255 Outer Green 5 0-255 Outer Blue 5 0-255 Outer Red 6 0-255 Outer Green 6 0-255 Outer Blue 6 0-255 Outer Red 7 0-255 Outer Green 7 0-255 Outer Blue 7 0-255...
Page 26 Delivery - Expolite Retron LED 575 - Power connection cable - General Information for Expolite Units - User Manual Expolite devices are carefully checked before shipment. If the delivery is not complete, please contact your distributor immediately. E-26...
Page 27: Product Information
Product Information Voltage 100V - 240V AC 50/60Hz Power Consumption 400W Dimensions 462 x 271 x 493 mm Weight 8 kg Connectors Power In/Out | DMX In/Out Ambient Temperature -20°C - 45°C Humidity < 98% Protection IP 20 Housing Coated Metal LEDs 462 x OSRAM (192 x RGB LEDs Outer Ring, 144 x RGB LEDs Inner Ring, 108 x WW LEDs + 18 x...
Page 28: Dimensions
Dimensions E-28...
Page 29: Installation
Installation Mounting Hanging The ﬁxture has a 12,5mm hole in the bracket to mount spigots or half coupler up to M12.Fixture must be safe mounted in accordance with the relevant regulations and provided with a safetycord to prevent falling. For this purpose, an eyelet for safeties is attached to the device. Standing The ﬁxture can be mounted in an upright or sitting position.
Page 30: Operation
Operation Display Operation Return to previous menu Enter currently selected menu Scroll up, Increase value Scroll down, Decrease value Menu Map MENU Address 0 - 255 Conﬁg Mode Channel Mode 16Ch 51Ch 55Ch 64Ch Disable Keep Screen On Enable Keep DMX Data Disable Enable Fast Dimmer...
Page 31 Setting DMX-Address MENU Address 0 - 255 The DMX start address of the ﬁxture is set in the menu ADDRESS. This is retained even when changing the Chanel Mode. Setting DMX-Channels MENU Conﬁg Mode Channel Mode 16Ch 51Ch 55Ch 64Ch The user can set the DMX Channel Mode In Conﬁg Mode, submenu Channel Mode.
Page 32 Miscellaneous MENU System Info Temperature Load Default TRUE FALSE LED All On LED all on Auto Mode Speed 0 - 255 Auto Test Speed Auto Test Auto Mode 1 Auto Mode 2 Auto Mode 3 Auto Mode 4 Auto Mode 5 Auto Mode 6 System Info\Temperature: shows current temperature of the LED-Unit.
Page 33: Using Dmx512 Controller
Using DMX512 Control DMX-Channel assignment This device has several DMX personalities. In each personality a diﬀerent number of DMX channels is used and the reaction of the device diﬀers accordingly. There are six DMX personalities with 2, 7, 16, 51, 55 and 64 channels selectable. Because of changes in the ﬁrmware of the ﬁxture, functions can be added or changed.
Page 34 16Ch Mode 0-255 Master 0-255 Outer Red 0-255 Outer Green 0-255 Outer Blue 0-255 Inner Red 0-255 Inner Green 0-255 Inner Blue 0-255 Center Warm White 0-255 Center Amber 0-255 Back Warm White Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167...
Page 35 51Ch Mode 0-255 Outer Red 1 0-255 Outer Green 1 0-255 Outer Blue 1 0-255 Outer Red 2 0-255 Outer Green 2 0-255 Outer Blue 2 0-255 Outer Red 3 0-255 Outer Green 3 0-255 Outer Blue 3 0-255 Outer Red 4 0-255 Outer Green 4 0-255...
Page 36 0-255 Inner Red 7 0-255 Inner Green 7 0-255 Inner Blue 7 0-255 Inner Red 8 0-255 Inner Green 8 0-255 Inner Blue 8 0-255 Center Warm White 0-255 Center Amber 0-255 Back Warm White E-36...
Page 37 E-37...
Page 38 0-255 All LED Strobe (Slow to fast) 0-255 Outer Strobe (Slow to fast) 0-255 Inner Strobe (Slow to fast) 0-255 Center Strobe (Slow to fast) Dimmer Speed 0-254 Fast to slow Tungsten 0-255 Inner Red 1 0-255 Inner Red 2 0-255 Inner Red 3 0-255...
Page 39 0-255 Outer Green 7 0-255 Outer Green 8 0-255 Outer Blue 1 0-255 Outer Blue 2 0-255 Outer Blue 3 0-255 Outer Blue 4 0-255 Outer Blue 5 0-255 Outer Blue 6 0-255 Outer Blue 7 0-255 Outer Blue 8 E-39...
Page 40 New DMX-Channel Personalities since August 2018: 2Ch Mode 0-255 Master Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 7Ch Mode 0-255 Master 0-255 Outer Dimmer Outer Strobe 0-10 No function 11-240 Slow to fast...
Page 41 16Ch Mode 0-255 Master 0-255 All LED Strobe (slow to fast) Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 Dimmer Speed 0-254 Fast to slow Tungsten Effect 0-255 Outer Red 0-255 Outer Green...
Page 42 51Ch Mode 0-255 Outer Red 1 0-255 Outer Green 1 0-255 Outer Blue 1 0-255 Outer Red 2 0-255 Outer Green 2 0-255 Outer Blue 2 0-255 Outer Red 3 0-255 Outer Green 3 0-255 Outer Blue 3 0-255 Outer Red 4 0-255 Outer Green 4 0-255...
Page 43 0-255 Inner Blue 4 0-255 Inner Red 5 0-255 Inner Green 5 0-255 Inner Blue 5 0-255 Inner Red 6 0-255 Inner Green 6 0-255 Inner Blue 6 0-255 Inner Red 7 0-255 Inner Green 7 0-255 Inner Blue 7 0-255 Inner Red 8 0-255...
Page 44 55Ch Mode 0-255 Master 0-255 Outer Red 1 0-255 Outer Green 1 0-255 Outer Blue 1 0-255 Outer Red 2 0-255 Outer Green 2 0-255 Outer Blue 2 0-255 Outer Red 3 0-255 Outer Green 3 0-255 Outer Blue 3 0-255 Outer Red 4 0-255...
Page 45 0-255 Inner Red 5 0-255 Inner Green 5 0-255 Inner Blue 5 0-255 Inner Red 6 0-255 Inner Green 6 0-255 Inner Blue 6 0-255 Inner Red 7 0-255 Inner Green 7 0-255 Inner Blue 7 0-255 Inner Red 8 0-255 Inner Green 8 0-255...
Page 46 64Ch Mode 0-255 Master 0-255 All LED Strobe (Slow to fast) Flow Effect 0-41 No Function 42-83 Effect 1 84-125 Effect 2 126-167 Effect 3 168-209 Effect 4 210-255 Effect 5 Dimmer Speed 0-254 Fast to slow Tungsten Effect 0-255 Outer Red 0-255 Outer Green...
Page 47 0-255 Outer Green 4 0-255 Outer Blue 4 0-255 Outer Red 5 0-255 Outer Green 5 0-255 Outer Blue 5 0-255 Outer Red 6 0-255 Outer Green 6 0-255 Outer Blue 6 0-255 Outer Red 7 0-255 Outer Green 7 0-255 Outer Blue 7 0-255...
