Internet Radio
Please read and retain these instructions for future reference
Radio:
Frequencies:
Display :
Network:
Media streaming:
Media streaming requires UPnP server/DLNA
Speaker:
Input:
Output connectors:
Mains power adapter:
Power consumption:
Dimensions:
Weight:
Please read this instruction manual thoroughly before starting and ensure you are familiar with the
operation of your new
Internet Radio.
Page No. 1
G040
Digital (DAB/DAB+), FM and internet radio (via Wi-Fi).
Digital Band III 174–240 MHz, FM 87.5-108 MHz (with RDS).
2.4", 320 x 240, TFT colour display.
Wi-Fi: 802.11b, 802.11g and 802.11n supported with WEP and WPA/WPA2
encryption, WPS.2.412 GHz ~ 2.472 GHz (channels 1 to 13). Maximum power:
16.00 dBm (EIRP) 0.5 MB broadband speed recommended.
Bluetooth, Frequency range: 2402 < 2480 MHz, Maximum power: 3.5 dBm
(EIRP)
Audio codec's supported include WMA, AAC, MP3, FLAC.
3.0" full range driver, 4W output
connectors 6.5 V DC power adapter socket.
3.5mm stereo phoner out socket
6.5 V DC, 3000mA (adapter supplied).
Standby mode: <1 W.
195mm wide x 118mm deep x 110mm high
1.08kg
Instructions for Use
v001: 17/06/19
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford G040
Summary of Contents for Coopers of Stortford G040
- Page 1 Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 Radio: Digital (DAB/DAB+), FM and internet radio (via Wi-Fi). Frequencies: Digital Band III 174–240 MHz, FM 87.5-108 MHz (with RDS). Display : 2.4", 320 x 240, TFT colour display.
-
Page 2: Table Of Contents
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 Contents GETTING STARTED ............................. 3 ACCESSORIES INCLUDED ..........................3 GETTING STARTED ............................4 Adjusting and muting the volume ......................... 5 INTERNET LISTENING ............................. 5 Listening to internet content ......................... -
Page 3: Getting Started
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 CONTROL LOCATIONS FRONT PANEL CONTROLS Description Function Power Press to switch between on and standby. Source Press to switch source. Preset If listening to an internet, digital or FM radio station, press to save the radio station as a preset. -
Page 4: Getting Started
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 Please verify that you have all the following accessories before recycling the gift box. User Manual GETTING STARTED Quick set up 1. • Unclip the aerial and fully extend it (steps A and B). -
Page 5: Adjusting And Muting The Volume
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 3. The first time you switch on you will be asked if you would like to run the setup wizard, which will help you connect to your Wi-Fi. If you want to run the setup wizard now, turn and press the Select dial to select ‘Yes’... -
Page 6: Listening To Internet Content
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 LISTENING TO INTERNET CONTENT Thousands of radio stations around the world broadcast online. To listen to an internet radio station or podcast: 1. Press the Source button to display the ‘function’... -
Page 7: Podcasts
3. Start the pairing process on your mobile device. Do this by selecting ‘G040’ from the list of available devices that appear on the mobile device’s screen. Your mobile device will connect automatically once paired. -
Page 8: Listening To Dab Or Fm Radio
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 2. Turn and press the Select dial to select ‘Yes’ to disconnect your mobile device. If your mobile device goes out of Bluetooth range (this is usually around 10m (30ft)) the mobile device’s Bluetooth connection is disconnected automatically. -
Page 9: Changing Fm Stations
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 3. Press Select dial to select YES and press select button to confirm. Or select NO to cancel. DRC (Dynamic Range Compression) If you are listening to music with high dynamic range in a noisy environment, you may wish to compress the audio dynamic range 1. -
Page 10: Sleep Setting
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 Time: Turn and press the Select dial to adjust the hour of the alarm. Note: If you have set to use the 12 hour time format, make sure that you select the ‘AM’ or ‘PM’ version of the hour before pressing the Select dial. - Page 11 Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 4. Turn and press the Select dial to set the day of the month. Repeat to set the month and year. 5. Turn and press the Select dial to set the hour. Repeat to adjust the minutes.
-
Page 12: Network Settings
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 3. Turn and press the Select dial to choose ‘Inactive Standby ’. 4. Turn and press the Select dial to choose between the Off - > 2 hours > 4 hours > 5 hours > 6 hours. -
Page 13: Warnings And Safety Instructions
SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND CAUSE BURNS. PARTICULAR ATTENTION HAS TO BE GIVEN WHERE CHILDREN AND VULNERABLE PEOPLE ARE PRESENT. THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE. ... -
Page 14: Plug Wiring (Uk & Ireland)
Internet Radio Instructions for Use G040 Please read and retain these instructions for future reference v001: 17/06/19 • ANY REPAIRS MUST BE CONDUCTED BY A QUALIFIED ELECTRICIAN OR ELECTRICAL SERVICE AGENT. PLUG WIRING (UK & IRELAND) This appliance is supplied with a mains adaptor/charger with BS1363 plug pins.
