TOUCH SCREEN MANUAL TIMER (TSMT)
This remote control transmitter provides a multifunctional, reliable and user-friendly remote control for the fireplace system. The
transmitter can manually turn the system on and off. Always check the appliance home owner's manual for additional informa-
tion, or warnings regarding accessory installation before using this remote control system.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the dealer from
whom you purchased the kit or Ambient Technologies Technical Support at 1 800 398 6195. Do not attempt to install any part of
the kit unless all parts are in good condition. Please keep this booklet for future reference.
f i r e - p a r t s . c o m
•
Large LCD display
•
Touch Screen Panel
•
Timer Mode
•
Sleep Mode to Save Battery
•
Low battery Indication on Transmitter
•
Child Proof Lock-out
•
LCD Backlight
•
On-screen Security Codes Setup on Transmitter
•
16 Security Codes (DIP Switches) on Receiver
•
Optional 6 Hour Shut Down on Receiver
•
Quick Disconnect Wiring Assembly
OPERATING INSTRUCTIONS
Transmitter
Mounting Base
Battery Alkaline AAA
#6C\v" Screws, Zinc
Receiver (Assembly) consists of:
Receiver Box
Slide Button-Black (On/RS/Off)
Battery Alkaline AA (for receiver)
Wall Cover Plate - Black
Wall Cover Plate - White
Slide Button - White (On/RS/Off)
Battery Door - White
Plug-in Wiring Assembly - 22"
Velcro (Loop and Hook)
Installation Instructions
#6 3/4" Screws, Zinc (for Wall Cover Plate)
#8 Screws (for fireplace system control covers)
CONTENTS OF KIT
Description
FEATURES
Qty
1
1
4
2
1
4
1
1
1
1
1
1
1
2
2
20300538 10/09 Rev. 0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Ambient Technologies TSMT
- Page 1 Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the dealer from whom you purchased the kit or Ambient Technologies Technical Support at 1 800 398 6195. Do not attempt to install any part of the kit unless all parts are in good condition.
- Page 2 Touch Screen Transmitter Manual Timer Instructions WARNING Important Safey Information • This remote control system should only be used as described in this manual. Any other use is not recommended and will void the warranty. • Read this manual thoroughly prior to installing, programming or operating any remote control. •...
-
Page 3: Installations
Touch Screen Transmitter Manual Timer Instructions INSTALLATIONS Receiver The remote receiver may be wall mounted or installed in the appliance per the appliance homeowner’s manual. Refer to the Homeowner’s Manual for special installation in- structions. If wall mounted, the remote receiver must be installed in a junction box with cover plate provided. -
Page 4: Lcd Display
Transmitter n Function Areas of the LCD Display The figure on the right shows the display of the TSMT LCD. Information Bar The information bar shows the room temperature, the “sending signal” radio icon, the low battery indication icon, the child-proof icon, and the flame icon. -
Page 5: Privacy Code
Touch Screen Transmitter Manual Timer Instructions To install batteries, 1. Press down the battery door tab and pull out to remove the battery door. 2. Install the batteries as indicated inside the battery compartments. 3. Close the battery door by snapping in place. 4. -
Page 6: Manual Mode
Functions and Operations General: The TSMT Remote Control has two (2) operating modes: Manual and Timer. The transmitter will operate the remote receiver from 1 foot to a maximum of 30 feet. The distance is reduced when f i r e - p a r t s . c o m batteries are low. -
Page 7: Safety Features
Touch Screen Transmitter Manual Timer Instructions n Safety Features 1. Low Battery Detection When low battery condition occurs, the transmitter will turn off the fireplace. A) Battery voltage is checked every one minute. When the battery voltage is low, the LCD displays a low bat- tery icon which will exist in all modes. -
Page 8: Warranty
