Energetic Lighting ELYRTD Series Installation Instructions

Led recessed troffer retrofit kit

LED Recessed

Troffer Retrofit Kit

ATTACH YOUR RECEIPT HERE

Item Number

Purchase Date

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-866-492-6566.

Model # ELYRTD series

www.energeticlighting.com

Table of Contents

Need help?

Do you have a question about the ELYRTD Series and is the answer not in the manual?

Page 1 Model # ELYRTD series LED Recessed Troffer Retrofit Kit Installation Instructions ATTACH YOUR RECEIPT HERE Item Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-492-6566. www.energeticlighting.com...
Page 2 PACKAGE CONTENTS SAFETY INFORMATION WARNING • To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or Part Item Name Qty. other sharp objects. Retro t assembly • Do not make or alter any open holes in an enclosure of wiring or electrical components Bracket Sheet metal screw during kit installation.
Page 3 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 2. Slide the two brackets (B) on each side (2-ft ends) of 5. Hook the safety cables onto a hook or hole on the the existing fixture housing so that the flat base is fixture housing as a secondary safety support. resting between the existing fixture edge and the drop ceiling T-grid support lip.
Page 4 TROUBLESHOOTING Problem Possible Solution Corrective Action 1. Power is off. 1. Check circuit breaker or wall switch. Fixture does not light. 2. Incorrect wire connection. 2. Check wire splices. 3. Defective wall switch. 3. Replace switch. Circuit breaker trips Crossed wires or power Verify wires are correctly when light is turned on.
