DualLite CLSC Quick Start Manual

Chicago approved battery backup led exit & unit combo no panel version
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions should
READ AND FOLLOW ALL SAFETY
Warning: FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS MAY RESULT IN DEATH,
SERIOUS INJURY OR SIGNIFICANT PROPERTY DAMAGE - For your protection, read and follow these
warnings and instructions carefully before installing or maintaining this equipment. These instructions
do not attempt to cover all installation and maintenance situations
Warning: RISK OF ELECTRIC SHOCK. NEVER CONNECT TO, DISCONNECT
FROM, OR SERVICE WHILE EQUIPMENT IS ENERGIZED.
Warning: RISK OF FIRE - Lamps are hot. Keep combustible material away from hot parts. Observe
lamp manufacturer's warnings, recommendations and restrictions on lamp operation and maintenance.
Make sure lamps are correctly installed.
Warning: DO NOT USE ABRASIVE MATERIALS OR OTHER SOLVENTS. USE OF THESE
SUBSTANCES MAY DAMAGE FIXTURE, WHICH MAY RESULT IN PERSONAL INJURY.
Warning: RISK OF PERSONAL INJURY. This product may have sharp edges. Wear gloves to prevent
cuts or abrasions when removing from carton, handling, installing and maintaining this product.
• Before wiring to power supply, turn off electricity at fuse or circuit breaker.
• Disconnect A.C. power and unplug battery before servicing.
• Consult your local building codes for approved wiring and installation.
• May be used outdoors under cover (0°C - 50°C; 32°F - 122°F).
• Do not let power supply cord touch hot surfaces.
• Do not mount near gas or electric heaters.
• Do not install a damaged fi xture.
• This product must be installed in accordance with the applicable installation codes and ordinances.
• All service shall be performed by qualifi ed service personnel. This product must be installed and maintained in accordance with the applicable
Installation codes by a person familiar with the construction operation of the product and the hazards involved.
• Equipment should be mounted in locations and at heights where it will not be subject to tampering by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer will void product listing and warranty and may cause an unsafe condition.
• Do not use this equipment for anything other than its intended use.
• The AC voltage rating of this equipment is specifi ed on the product label. Do not connect equipment to any other voltage.
WARNING – This product contains chemicals known to the State of California to cause cancer, birth
defects and/or other reproductive harm. Thoroughly wash hands after installing, handling, cleaning,
or otherwise touching this product.
Chicago Approved Battery Backup LED Exit & Unit Combo
always be followed including the following.
INSTRUCTIONS
CLSC
No Panel Version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLSC and is the answer not in the manual?

Questions and answers

Summary of Contents for DualLite CLSC

  • Page 1: Important Safeguards

    CLSC Chicago Approved Battery Backup LED Exit & Unit Combo No Panel Version IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following. READ AND FOLLOW ALL SAFETY INSTRUCTIONS Warning: FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS MAY RESULT IN DEATH, SERIOUS INJURY OR SIGNIFICANT PROPERTY DAMAGE - For your protection, read and follow these warnings and instructions carefully before installing or maintaining this equipment.
  • Page 2 INSTALLATION Note: This EXIT fixture may be shipped with an extra FACE PANEL to make the sign double face. Replace the BACKPLATE with the extra FACE PANEL at the start of the installation process if the application calls for a double face sign.
  • Page 3 OPERATION OPERATION: EXIT - LED lamps will stay on in AC mode and remain on in the Emergency mode. To perform TEST, press the TEST switch. LAMP HEADS - To test the equipment, depress the TEST switch. The charge (LED) indicator will turn OFF and the emergency lights will illuminate.
  • Page 4 STEP 3: Slide the panel(s) through the channel. Replace the panel cover using the screw (previously removed in STEP 2). Panel assembly process should now be complete. CLSC Compatability Chart FIXTURE/HOUSING PART# COMPATIBLE PANEL (S) PART #...
