Summary of Contents for Symmetry Office APEX-SYMAC Series

  • Page 1 Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation APEX-SYMAC1 APEX-SYMAC2 APEX-SYMAC3 APEX-SYMAC2D Apex Column Mounts Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description APEX-SYMAC Series...
  • Page 2: Important Safety Instructions

    Symmetry Office makes result in collapse of the mount and its accessories causing no representation of warranty, expressed or implied, regarding possible injury.
  • Page 3 Installation Instructions APEX-SYMAC Series DIMENSIONS APEX-SYMAC1 10 DOWN MOUNTING PATTERN HEIGHT ADJUST RANGE COMPATIBILITY MANUAL (7") + DYNAMIC (13") 100 X 100 26.30 75 X 75 6.30 667.9 159.9 DESKTOP THICKNESS RANGE 2.50 63.5 12.7 APEX-SYMAC2 INTERFACE MOUNTING PATTERN ROTATION...
  • Page 4 APEX-SYMAC Series Installation Instructions APEX-SYMAC2D MOUNTING PATTERN COMPATIBILITY 100 X 100 75 X 75 INTERFACE ROTATION RANGE 10 DOWN DESKTOP THICKNESS RANGE 2.50 63.5 12.7 APEX-SYMAC3 INTERFACE MOUNTING PATTERN COMPATIBILITY 10 DOWN 100 X 100 75 X 75 HEIGHT ADJUST RANGE MANUAL (7") + DYNAMIC (13")
  • Page 5 Installation Instructions APEX-SYMAC Series LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
  • Page 6: Tools Required For Installation

    APEX-SYMAC Series Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16” (included) 1/8” (included) PARTS A (1) A (1) [APEX-SYMAC1] A (1) [APEX-SYMAC2D] [APEX-SYMAC2] A (1) * - (single display models/dual display models) [APEX-SYMAC3] B (4/8)* D (4/8)* C (4/8)* M4x14mm M4x25mm M10x5.3x10...
  • Page 7: Assembly And Installation

    Installation Instructions APEX-SYMAC Series Assembly And Installation Grommet Hole Option APEX-SYMAC Series mounts may be installed directly NOTE: Connecting Desk Clamp Arms to Desk to grommet holes between 1 1/4” and 2 1/2” in Standard Installation diameter. If grommet hardware (F-H) is used, they can be installed to grommet holes between 3/8”...
  • Page 8 APEX-SYMAC Series Installation Instructions Using Grommet Hardware Array Installation (APEX-SYMAC2D ONLY) Remove desk clamp from mount by loosening button head Slide rotational spacer (J10) into opening on array cap screw until clamp is completely disengaged from the attachment bracket. (See Figure 7) bolt.
  • Page 9: Display Installation

    It is the installer’s responsibility to make sure the combined weight of For recessed mounting hole installation: all components located between the APEX-SYMAC Series • Place four spacers (D) on top of mounting holes Monitor Arm and the desk up to (and including) the display on back of display.
  • Page 10 APEX-SYMAC Series Installation Instructions Position display with faceplate attached above mount. (See Figure 11) Slide faceplate onto mounting head until quick release tab clicks into place. (See Figure 11) Figure 13 Adjustments Pitch Adjustment (non-array models) Adjust pitch to desired tilt position. (See Figure 14)
  • Page 11 Installation Instructions APEX-SYMAC Series Rotational Adjustment NOTE: (Optional) Rotational adjustment may be locked by installing rotational locking screw (E) into back of faceplate. (See Figure 15) Reduce tension (lighter display) Increase tension (heavier display) Do NOT over-tension adjustment tension screw.
  • Page 12: Display Removal

    APEX-SYMAC Series Installation Instructions Array Bar Roll Adjustment Loosen roll adjustment screws on back of array bracket. (See Figure 19) Adjust roll of array bar as desired. (See Figure 19) Tighten roll adjustment screws on back of array bracket. (See Figure 19)
  • Page 13: Cable Management

    Installation Instructions APEX-SYMAC Series APEX-SYMAC2/SYMAC3 Adjust arm angles as desired within a 90 degree range from the pivot point of the arm and a perpendicular centerline of mount. (See Figure 22) Swinging the arm beyond this range may result WARNING:...
  • Page 14 APEX-SYMAC Series Installation Instructions...
  • Page 15 Installation Instructions APEX-SYMAC Series...
  • Page 16 APEX-SYMAC Series Installation Instructions Symmetry Office 7818 Depot Lane Tampa, FL 33637 888-552-5699 8800-002656 Rev00 09/14 www.symmetryoffice.com...
