Strike Guard

LIGHTNING WARNING SYSTEM

SER

UIDE

Strike Guard Lightning Warning System

DEC 2013

Table of Contents

Need help?

Do you have a question about the Strike Guard and is the answer not in the manual?

Questions and answers

Summary of Contents for WXLINE Strike Guard

Page 1 Strike Guard LIGHTNING WARNING SYSTEM ’ UIDE Strike Guard Lightning Warning System DEC 2013...
Page 2: Table Of Contents
STRIKE GUARD LIGHTNING WARNING SYSTEM....SECTION 4 STRIKE GUARD LIGHTNING SENSOR........SECTION 5 STRIKE GUARD LIGHTNING DATA RECEIVER....... SECTION 6 ACHIEVING TOP PERFORMANCE AND LONGEST LIFE FROM THE STRIKE GUARD LIGHTNING WARNING SYSTEM …..22 SECTION 7 LIGHTNING WARNING SYSTEM QUICK REFERENCE INSTALLATION GUIDE AND CHECKLIST........
Page 3: Contact
SECTION 1 CONTACT For technical assistance and sales please contact Wxline, LLC or a local representative. Wxline, LLC 3924 North Calle Casita Tucson, Arizona 85718 Tel: ++ 520.615.9999 Toll Free: 800.615.0340 Fax: ++ 520.615.0030 info@wxline.com Email: Strike Guard Lightning Warning System...
Page 4: Warranty
Wxline, LLC neither assumes nor authorizes any person to assume for Wxline, LLC any other liability in connection with the sale or use of the goods sold and there are no oral agreements or warranties collateral to or affecting this agreement.
Page 5: Strike Guard Lightning Warning System
STRIKE GUARD LIGHTNING WARNING SYSTEM This guide is for installation and use of the Strike Guard Lightning Warning System. You are encouraged to call Wxline, LLC if you have questions concerning the Strike Guard System. A. ABOUT THE STRIKE GUARD LIGHTNING WARNING...
Page 6 To ensure total immunity from lightning disruption of communications during a local thunderstorm, the Strike Guard Sensor is connected to the Strike Guard Lightning Data Receiver via a non-conducting, fiber-optic link. The Strike Guard Lightning Warning System is designed for easy installation using a minimum of tools and specialized knowledge.
Page 7 E. HANDLING PRECAUTIONS GLASS DIFFUSER The Strike Guard Lightning Sensor has a glass diffuser dome that may break with rough handling or impact from hard tools. Use extra care in handling the Sensor. Ship and transport the Sensor in the factory foam and cardboard container.
Page 8 LEDs extinguish and only the blue LED flashes once every two seconds (approx). This is the normal indication. If this indication is not observed on the first try, go to Step 6 and reattempt this initial test. Call Wxline if problems persist at this step.
Page 9: Section 4 Strike Guard Lightning Sensor
9. With the Lightning Data Receiver turned ON and with Strike View Software running and with all fiber-optic connections in place, pick up the Strike Guard Lightning Sensor and turn it UPSIDE DOWN for at least 10 seconds. Now turn the Sensor right side up and set it on the desktop.
Page 10: Strike Guard Lightning Sensor
The primary goals of Sensor mounting are: • Security from tampering and vandalism • Good exposure to the whole sky • Rigidity and freedom from vibration – if the Sensor vibrates on it’s mounting it will NOT function properly Strike Guard Lightning Warning System DEC 2013...
Page 11 Run the two stainless steel bolts through the saddle brackets and into the captive ¼-inch hardware on the side of the Sensor’s outer enclosure. Do not yet attach the Sensor to the mast. Strike Guard Lightning Warning System DEC 2013...
Page 12 The Strike Guard Lightning Warning System installation is completed successfully. C. PROBLEMS OR QUESTIONS If you have problems or questions, do not hesitate to call Wxline or your distributor. Most problems can be quickly solved with a short phone consultation. Strike Guard Lightning Warning System...
Page 13: Strike Guard Lightning Data Receiver
RECEIVER A. THE STRIKE GUARD LIGHTNING DATA RECEIVER The Strike Guard Lightning Data Receiver (LDR) receives serial data from the Strike Guard Lightning Sensor via a non-conducting, plastic fiber-optic communications link. The LDR decodes lightning and status messages and provides the logic and timing needed to give audible and visual lightning and status information and to provide contact-closure signaling of external equipment.
Page 14 One or more other red status LEDs may be flashing on power up. With the reception of the first PASS SELF TEST message from the Strike Guard Sensor, the No Communication LED will turn off along with any other status LEDs that were flashing on...
Page 15 LDR E. ABOUT JUMPER-SET OPTIONS The Strike Guard Lightning Data Receiver offers several shorting-jumper-set options to allow the user to select certain preferred features. These jumper-set options are preset at the factory to conservative values that are appropriate for many lightning warning settings.
Page 16 Warning typically gives a medium level of downtime and moderate level of safety. Setting this option to Alarm, typically gives the least number of lightning alarms, minimal downtime and the lowest level of lightning safety. Strike Guard Lightning Warning System DEC 2013...
Page 17 Category Threshold are required to start another active Alarm Interval. Setting this option to one gives the greatest margin of safety and setting this option to eight gives the least margin of safety. Strike Guard Lightning Warning System DEC 2013...
Page 18 The black wire is circuit and chassis ground from the QPS Master Control Transmitter and it must be made common with the circuit and chassis ground (terminal 7 of J202) of the LDR as shown above. Strike Guard Lightning Warning System DEC 2013...
Page 19 – thus WAVE Siren functions will not occur. For proper safe operation of the Strike Guard Lightning Warning System it is essential to have a functioning battery back-up system available. The LDR relays cannot be controlled reliably in thunderstorm conditions without good batteries.
Page 20 If an LDR is stored for more than 2 years, install fresh batteries before use. With fresh batteries, expected battery life is approximately 3 years of no battery run time or about 150 hours of battery operation time, whichever comes first. Strike Guard Lightning Warning System DEC 2013...
Page 21: Achieving Top Performance And Longest Life From The Strike Guard Lightning Warning System
LONGEST LIFE FROM THE STRIKE GUARD LIGHTNING WARNING SYSTEM There are no user-serviceable parts inside the Strike Guard Sensor and we do not recommend breaking the seal of the Sensor for any reason as in doing so, there is increased likelihood that the seal will not be re-made properly.
Page 22 Every 3 to 4 years, the Sensor should be returned to the factory for complete factory recertification involving recalibration, refurbishment and installation of any upgrades. Critical measurement and safety equipment such as the Strike Guard Lightning Warning System must be periodically serviced and certified to ensure proper operation.
Page 23: Lightning Warning System Quick Reference Installation Guide And Checklist
LIGHTNING WARNING SYSTEM QUICK REFERENCE INSTALLATION GUIDE AND CHECKLIST This document is a supplement to more comprehensive Strike Guard User’s Guides. Please refer to the applicable Strike Guard documents for detailed information and instructions. NOTE Perform Step 1 through Step 8 in an indoor environment to ensure the proper function of all system components before proceeding with the permanent installation.
Page 24 (97.5 feet) is supplied with a standard Strike Guard system. Protective plastic caps are installed on fiber-optic cable that is prepared and shipped by Wxline. Remove plastic caps from the ends of the cable only after pulling and running fiber to protect the ends of the fiber from degradation.
Page 25 Check both ends of the fiber-optic cable to make sure that fiber is fully seated and that ferrules are tightened. Check all Sensor and tripod mounting hardware to make sure it is snug. Now the Strike Guard Lightning Warning System is installed and operating. Strike Guard Lightning Warning System...
Page 26: Connecting Equipment To The Lightning Data Receiver Quick Reference Guide And Checklist
The black wire is circuit and chassis ground from the QPS Master Control Transmitter and it must be made common with the circuit and chassis ground (terminal 7 of J202) of the LDR as shown above. Strike Guard Lightning Warning System DEC 2013...
Page 27 Receiver should be powered continuously, except for periods of routine maintenance. The on-board batteries will reliably maintain relay states during failures of commercial power (150 hours typical back up time for fresh alkaline batteries). Strike Guard Lightning Warning System DEC 2013...
Page 28: Strike View Software Quick Reference Installation Guide And Checklist
SECTION 9 STRIKE VIEW SOFTWARE QUICK REFERENCE INSTALLATION GUIDE AND CHECKLIST Strike View Software expands on the capabilities of the Strike Guard Lightning Data Receiver. Strike View provides data display, data logging functions, and Email notification. NOTE Strike View only ingests and processes Sensor data and status messages.
Page 29 Awaiting Sensor Message Mode is the first mode shown upon initial startup of Strike View Server. Awaiting Sensor Message Mode changes to No Lightning Detected Mode if no data is sent from the Strike Guard Receiver except Sensor Status information. If Sensor Status information is not received within 2 hours of operation of Strike View Server, Failure Mode is indicated.
Page 30 No Lightning Detected Mode remains in effect provided that no data is sent from the Strike Guard Receiver except routine Sensor Status information. If lightning data is sent from the Strike Guard Receiver to the computer, Strike View Server Mode changes to Caution, Warning, or Alarm Mode based on the proximity of the lightning flash detected.
Page 31: Diagrams
The following pages include diagrams that supplement the written information in this User’s Guide. Diagrams include: • Strike Guard & WAVE Siren Drawing • Strike Guard & WAVE Siren & Sequencers Drawing • Strike Guard Lightning Data Receiver Diagram • Receiver Board - Addendum 1 •...
Page 32 Strike Guard Lightning Warning System DEC 2013...
Page 33 Strike Guard Lightning Warning System DEC 2013...
Page 34 Strike Guard Lightning Warning System DEC 2013...
Page 35 Strike Guard Lightning Warning System DEC 2013...
Page 36 Strike Guard Lightning Warning System DEC 2013...
Page 37 Strike Guard Lightning Warning System DEC 2013...
