Romus Surf'In 95320 Instructions For Use Manual

Groove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SURF'IN GROOVE MILLING MACHINE
Ref. 95320
INSTRUCTIONS FOR USE – EN – V.001 dated 10/12/18
This user manual refers to the above machine.
The original of this user manual was written in French (any user manual in another
language is a translation from the original).
It contains important information on its operation and handling.
Take this into account when you pass the product on to third parties.
Keep these instructions for future reference!

Advertisement

Table of Contents
loading

Related Manuals for Romus Surf'In 95320

Summary of Contents for Romus Surf'In 95320

  • Page 1 SURF’IN GROOVE MILLING MACHINE Ref. 95320 INSTRUCTIONS FOR USE – EN – V.001 dated 10/12/18 This user manual refers to the above machine. The original of this user manual was written in French (any user manual in another language is a translation from the original). It contains important information on its operation and handling.

  • Page 2: Table Of Contents

    Surfin groove milling machine | Ref. 95320 Table of contents Warnings Description Applications Technical data Accident prevention regulations 1.2 noise (VGB 121) Introduction Risks when handling the machine Use compliant with intended purpose Original spare parts and safety Warranty Description of the operating station Blade change Transport Servicing and maintenance...

  • Page 3: Description

    19. Recharge the batteries only with the charger provided BATTERY USE AND MAINTENANCE Recharge only with the charger specified by ROMUS. A charger which is suitable for one type of batteries may create a fire risk if it is used with another type of batteries Use tools only with specially designated batteries.

  • Page 4: Applications

    Surfin groove milling machine | Ref. 95320 Electric groove milling machine . A motor drives a blade which cuts a groove in the floor covering. Applications For cutting grooves in all types of flexible floor covering, such as PVC, linoleum, etc. Technical data Voltage (V): Revolutions per minute (rpm):...

  • Page 5: Risks When Handling The Machine

    Usage other than for this purpose or over and above it shall be deemed non-compliant with the intended purpose and ROMUS shall not be liable under the warranty for any resulting damage.

  • Page 6: Description Of The Operating Station

    ROMUS after-sales department. Any attempt by a user or unauthorised staff member to dismantle or modify a component leads to expiry of the warranty, and ROMUS shall not be liable for any damage or injury to the persons and objects concerned by these modifications. Thus, ROMUS shall not be...
  • Page 7 Battery installation and removal Charging the battery Use only the Romus charger supplied. Only these chargers are compatible with the lithium ion battery used in your power tool. Note: The battery is supplied in a low charge state. To guarantee its full output, charge it in the charger before first start-up for at least 2 hours.
  • Page 8 Surfin groove milling machine | Ref. 95320 The depth of the groove depends on the thickness and nature of the covering: For homogeneous PVCs and linoleums, cut the groove to 2/3 of the thickness of the covering. For non-homogeneous PVCs, cut the groove only in the wear layer. Move the knurled depth adjustment knob (A) until the cursor (B) is opposite the desired depth.

  • Page 9: Blade Change

    Surfin groove milling machine | Ref. 95320 Insert the narrow front caster (A) into the joint and align the rear wide caster (B) with the joint. Press simultaneously on the unlocking detente (C) and the On/Off switch (D) located under the handle and hold the latter down.
  • Page 10 Surfin groove milling machine | Ref. 95320 Remove the bag Remove the battery Use the wrench supplied to unscrew the two cap screws Swivel the cap and then, by pressing on the shaft locking button (A), unscrew the blade screw (B) clockwise with the wrench supplied Remove the pin, then the worn blade and replace it, paying attention to the direction of rotation...

  • Page 11: Servicing And Maintenance

    Surfin groove milling machine | Ref. 95320 Position the pin (B) by turning it until it clicks, so that it is embedded completely Press the shaft locking button (A) to tighten the blade screw (B) anticlockwise, using the wrench provided, then lower the cap, retighten the two cap screws and store the wrench in its housing.
  • Page 12 Surfin groove milling machine | Ref. 95320...
  • Page 13 Surfin groove milling machine | Ref. 95320 The undersigned design and production company CE Declaration of Conformity The undersigned design and production company Romus 13/15 rue du Taillefer ZA Les POUARDS 91160 CHAMPLAN Hereby declares, under its own responsibility, that the product...
