Water• Tite
Heavy Duty
Plastic Washing
Machine Pans
Provides protection from washing
machine overflow or hose failure.
Overview
Water-Tite Washing Machine Pans easily fit underneath machines
to prevent water damage to floors associated with washing
machine or hose leaks. The pans protect floors from scuffs, spills,
and overflows; and meets code for use in second floor laundry
rooms. The included PVC adapter will securely attach to a drain
line for water evacuation.
Features
• White, High-impact plastic – will not rust, corrode or crack
• 1" x 1½ PVC drain connection included
• Provides protection from washing machine overflow or hose failure
• Pan not drilled, design allows for many drain options
500 Distribution Parkway, Collierville, TN 38017 / 800-888-8312 • FAX 901-853-5008
www.ipscorp.com / watertite@ipscorp.com
Advertisement
Summary of Contents for IPS WATER-TITE
- Page 1 Provides protection from washing machine overflow or hose failure. Overview Water-Tite Washing Machine Pans easily fit underneath machines to prevent water damage to floors associated with washing machine or hose leaks. The pans protect floors from scuffs, spills, and overflows; and meets code for use in second floor laundry rooms.
-
Page 2: Installation Instructions
Installation Instructions Always check local codes before installation. Determine size of required washing machine pan. NOTE: Suggested to include a 1” to 2” gap around pan, from edge of pan to washing machine. Locate installation site of washing machine pan and find the preferred drain outlet location. Drill 1 ” hole and install the included 1”x 1½” PVC male adapter. NOTE: Install the adapter and rubber sealing washer from the outside of the pan and then attach the locking nut to the adapter threads from inside the pan.
