Summary of Contents for HiP HIP-10RV
- Page 1 HIP-10RV Field Adjustable Relief Valve Maintenance Instructions High Pressure Equipment Company 2955 West 17th Street, Suite 6 PO Box 8248 Erie, PA 16505 USA 814-838-2028 (phone) 814-838-6075 (fax) www.highpressure.com...
- Page 2 HIP-10RV Field Adjustable Relief Valve Operating Instructions: Operating Instructions: 1. Install HIP-10Rv in system. Inlet ports are located on the side of the body. Outlet port is located at the end of the body opposite of the handle. 2. Loosen the lock nut and back off handle until little or no spring tension is felt.
- Page 3 HIP-10RV Field Adjustable Relief Valve Maintenance Instructions: Disassembly Instructions: 1. Secure the assembly vertically in a soft –jawed vise with the handle at the top. 2. Loosen the nut. 3. Loosen the handle to relieve the spring compression. Loosen seat gland.
