PVS Mounts for use with
BK LK-series Cardio Equipment
This installation manual is for the following products:
BH-PVSMNT-LKT6/8 – Treadmill...................................page 3
BH-PVSMNT-LK500Ti / LK700Ti – Treadmill................page 4
BH-PVSMNT-LK500X(i) / LK700X – Elliptical................page 5
BH-PVSMNT-LK500R / LK500Ri – Recumbent Bike......page 6
BH-PVSMNT-LK500U / LK500Ui – Upright Bike............page 7
BroadcastVision Entertainment : www.broadcastvision.com
Tel (888) 330-4283 ext. 3, Email: support@broadcastvision.com
Page 1
Advertisement
Table of Contents
Related Manuals for BVE BH-PVSMNT-LKT6
Summary of Contents for BVE BH-PVSMNT-LKT6
- Page 1 PVS Mounts for use with BK LK-series Cardio Equipment This installation manual is for the following products: BH-PVSMNT-LKT6/8 – Treadmill…………………………..…page 3 BH-PVSMNT-LK500Ti / LK700Ti – Treadmill……….…...page 4 BH-PVSMNT-LK500X(i) / LK700X – Elliptical…………..page 5 BH-PVSMNT-LK500R / LK500Ri – Recumbent Bike……page 6 BH-PVSMNT-LK500U / LK500Ui –...
- Page 2 Installation Tips: 1. These mounts attach to the BH commercial series cardio equipment at the location of the 4 console bolts except for bike products which clamp onto the handlebars behind the console. 2. For non-bike products, remove the 4 factory console bolts then re-install the bolts with the mount in place.
- Page 3 BH-PVSMNT-LKT6 / LKT8 - TREADMILL No extra hardware needed. The existing console bolts secure the mount as well. The mount attaches to the treadmill with the same bolts that are already holding the console in place. This mount attaches to the bottom of the console with the existing console bolts.
- Page 4 BH-PVSMNT-LK500Ti / LK700Ti - TREADMILL No extra hardware needed. The existing console bolts secure the mount as well. The mount attaches to the treadmill with the same bolts that are already holding the console in place. To install this mount the console bolts must be removed, then the mount slides between the console and the treadmill and the existing bolts are re-installed.
- Page 5 BH-PVSMNT-LK500X(i) / LK700X - ELLIPTICAL No extra hardware needed. The existing console bolts secure the mount as well. The mount attaches to the treadmill with the same bolts that are already holding the console in place. To install this mount first remove the console and then install the mount in between the console and the elliptical frame.
- Page 6 BH-PVSMNT-LK500R / LK500Ri – RECUMBENT BIKE This mount attaches to the bottom side of the bar underneath the console using the provided handlebar clamp hardware. The power and coaxial cables should be run down the bike frame using wire loom, zip ties and tie mounts provided.
- Page 7 BH-PVSMNT-LK500U / LK500Ui – UPRIGHT BIKE This mount attaches to the bottom side of the bar underneath the console using the provided handlebar clamp hardware. The power and coaxial cables should be run down the bike frame using wire loom, zip ties and tie mounts provided.
