Manual Gallagher Garden & Pond kit M10 (072347)

Content

Garden & Pond kit M10 Roadmap ....................................................................................................................... 2

Contents of the kit ........................................................................................................................................... 2

Determine the type of fence ........................................................................................................................... 2

Part 1 - Electric fence for garden, yard, ponds or around the aviary .................................................................. 3

Step 1 - Placing the posts ................................................................................................................................ 3

Step 2 - Determine the desired height of your fence ..................................................................................... 3

Step 3 - Assemble the wire .............................................................................................................................. 3

Step 4 - Installation of the electric fence device ............................................................................................. 4

Step 5 - Connecting the earth pin and grounding ........................................................................................... 4

Step 6 - Connecting the fence ......................................................................................................................... 5

Step 7 - Switch on and test electrical installation ........................................................................................... 5

Part 2 - Electric plus/minus fence on a (garden) barrier or wall ......................................................................... 6

Step 1 - Required materials ............................................................................................................................. 6

Step 2 - Placing the ring insulators on a fence or wall .................................................................................... 6

Step 3 - Assembling wire 1 .............................................................................................................................. 7

Step 4 - Assembling wire 2 .............................................................................................................................. 7

Step 5 - Connecting the Plus and Minus wire fence........................................................................................ 8

Step 6 - Installation of the electric fence device ............................................................................................. 9

Step 7 - Switch on and test electrical installation ........................................................................................... 9

Useful tips .......................................................................................................................................................... 10

For a successful training of your pet, follow these 3 steps. .......................................................................... 10

Important information ....................................................................................................................................... 10

Table of Contents

Summary of Contents for Gallagher Garden & Pond kit M10

Page 1: Table Of Contents
Manual Gallagher Garden & Pond kit M10 (072347) Content Garden & Pond kit M10 Roadmap ........................2 Contents of the kit ............................2 Determine the type of fence ........................... 2 Part 1 – Electric fence for garden, yard, ponds or around the aviary ..............3 Step 1 – Placing the posts ..........................
Page 2: Garden & Pond Kit M10 Roadmap
Garden & Pond kit M10 Roadmap Planning Proper preparation is important. First make a sketch of your fence and determine whether you have enough materials to make the fence. Follow the steps below for a fast and successful installation of your electric fence. Contents of the kit (A) 1 pc.
Page 3: Part 1 - Electric Fence For Garden, Yard, Ponds Or Around The Aviary
Part 1 – E lectric fence for garden, yard, ponds or around the aviary Step 1 – P lacing the posts See the image above for further reference of the articles mentioned in this step-by-step plan. Determine the location of your desired fence and place a plastic pole (B) in the earth every 4 metres.
Page 4: Step 4 - Installation Of The Electric Fence Device
Tip: If the supplied cables are too short, you can order the ‘grounding cable’ specially designed for this through the gallagher.eu webshop. (e.g. item no. 065028, Grounding cable 1.6 mm 10 m on a roll.)
Page 5: Step 6 - Connecting The Fence
To properly test the device and the working of the fence, we recommend that you consider purchasing a voltage tester. For the voltage testers, see the gallagher.eu webshop. If you do not have a voltage tester, use a blade of grass to test the fence. To do this, hold the blade of grass between your thumb and forefinger and then place the end of the blade on the electric cord.
Page 6: Part 2 - Electric Plus/Minus Fence On A (Garden) Barrier Or Wall
(item no. 065028) Gallagher ground cable 1.6 mm on a roll of 10 m. Note, Step 5 in this step-by-step plan is based on the use of the above Gallagher ground cable which isn’t supplied as standard with the kit.
Page 7: Step 3 - Assembling Wire 1
Step 3 – A ssembling wire 1 Assembly of the Minus wire 1. Unroll the wire for approximately 25 cm and make a loop at the beginning of the wire. Close the loop using the supplied Vidoflex wire connector. 3.
Page 8: Step 5 - Connecting The Plus And Minus Wire Fence
Step 5 – C onnecting the Plus and Minus wire fence For a good and stable connection of your Plus/Minus fence, we recommend the use of the specially suited Gallagher ground cable (see step 1, required materials). Proceed as following: Connecting the Minus (ground) cable 1.
Page 9: Step 6 - Installation Of The Electric Fence Device
Step 6 – I nstallation of the electric fence device Correct installation is essential for proper, functional and safe working of your electric fence. The electric fence device (A) should be placed near a power outlet and the fence, but always in a sheltered environment, such as a shed or under a roof and always protected from direct weather.
Page 10: Useful Tips
To properly test the device and the operation of the fence, we recommend that you consider purchasing a voltage tester. For the voltage testers, see the gallagher.eu webshop. No electric impulse? Check the electric fence device, is it plugged in?
