- Page 1 TDX2 USER MANUAL...
- Page 3 Tannoy TDX2 Quick reference To access a channel press the appropriate channel’s ‘GAIN’ button. When you press the button once you will get that channel’s gain screen. To scroll through a channels’ parameters, use the ‘BACK’ and ‘NEXT’ keys. (If you press the gain button a second time, you will get the last parameter viewed.
-
Page 5: Table Of Contents
Contents Important Safety Information ... 7 1. Introduction ... 8 2. Unpacking the TDX2... 8 3. General Overview and Features... 8 3.1. Features... 8 4. Front Panel Functions ... 10 5. Rear Panel Functions ... 11 6. Operating the TDX2... 12 6.1. - Page 6 12.2. Grounding ... 31 13. Warranty ... 32 14. Appendices... 33 14.1. Appendix 1 : Limiter threshold... 33 14.2. Appendix 2: Default Xover Settings... 34...
-
Page 7: Important Safety Information
An example of this equipment has been tested and found to comply with the following European and international Standards for Electromagnetic Compatibility and Electrical Safety: Radiated Emissions (EU): RF Immunity (EU): Electrical Safety (EU): Important Safety Information Do not remove Covers. No user serviceable parts inside, refer servicing to qualified service personnel. -
Page 8: Introduction
1U high unit. For ease of use, the TDX2 is factory set for operation with Tannoy products. In addition to this, 19 user memories are available. - Page 9 Comprehensive standard specification includes 19 user memories and Tannoy preset memories. The TDX2 provides exceptional audio quality with a full >110dB dynamic range, high sampling rate and minimal filtering. AES / EBU digital inputs and outputs are available as an option.
-
Page 10: Front Panel Functions
4. Front Panel Functions 1. LCD Display - Shows menu options, output information and various parameters being adjusted. 2. Gain Keys - Two input and six-output ‘gain’ keys allow instant access to the gain screen for each channel. When a channel is selected the accompanying LED lights up. -
Page 11: Rear Panel Functions
5. Rear Panel Functions 1. Power Switch. 2. Mains Fuse - Located in a finger-proof fuse holder adjacent to the mains inlet. Always replace this fuse with the correct type as shown on the rear panel legend. (N.B. A spare fuse is located in this holder.) 3. -
Page 12: Operating The Tdx2
6. Operating the TDX2 6.1. Preliminary Set-up The following procedure should be followed when first installing the TDX2. Connect the unit to a mains outlet with the mains cable provided, via the IEC connector located on the back of the unit. The unit is switched on by flicking the power switch. -
Page 13: Menu Selections
6.4. Menu Selections The following menu selections are available. To access menus, see instructions under preliminary set-up above. Xover Sub-Menu: Load a Xover: Loads a pre-defined crossover. Design a Xover: Set-up wizard for designing a crossover. Store a Xover: Stores all output settings as a defined crossover. Erase a Xover Mem: Erases a Xover from the list Input Set-up Sub-Menu: Allows ganging of inputs. -
Page 14: Tdx2 Configurations
It should also be noted that the turnover frequency displayed on the TDX2 is the -3dB point for all slopes except 24dB Linkwitz-Riley where the -6dB point is shown. If the -6dB... - Page 15 distance (System Sub-menu) and is adjustable in 2.6 S steps (1mm), or in 0.8mm (or 0.003 feet) steps. Alternatively, to convert from units of time (i.e. milliseconds) to units of distance use the following formula, or change the input method in ‘delay time/distance’ in the System Sub-Menu.
-
Page 16: Block Diagrams Of X-Over Modes
7.5. Block Diagrams of X-Over modes Tannoy TDX2 2 2 Way + 2 Mono Sum X-Over Tannoy TDX2 2 3 Way X-Over... - Page 17 Tannoy TDX2 4 Way + 2 X-Over Tannoy TDX2 5 Way + 1 X-Over...
- Page 18 Tannoy TDX2 6 Way X-Over...
-
Page 19: Output Limiters
7.6. Output Limiters High performance digital limiters are provided for each output with control over attack time, release time and threshold level parameters (see Section 8.2, page 22). This level of control allows the user to balance the required subjective quality of the limiter against the driver protection requirements. -
Page 20: Function Screens
Parametric filters are carefully implemented using Double Precision processing. This method is costly in terms of processing power but yields substantial benefits in terms of the TDX2’s exceptional noise performance and greatly improved low frequency stability. To adjust parametric settings: Select relevant channel by pressing the channel ‘GAIN’... -
Page 21: High And Low Pass Filter Screens
8.2. High and Low pass filter Screens OP1+4 < 10Hz Each output has an independent high pass filter and an independent low pass filter. Both filters have a range of selectable slopes, which are Bessel 12dB, 18dB and 24dB, Butterworth 12dB, 18dB and 24dB, and Linkwitz-Riley 24dB. High pass filters have a range of <10Hz (through) to 16kHz and Low pass filters have a range of 22kHz (through) to 35.1Hz in 1/36 octave steps. -
Page 22: Limiter Screen
8.3. Limiter Screen OP2+5 Atk:4.0mS Rx16 Each output has an independent high performance limiter. All limiters have an attack range of 0.3mS to 90mS, release times are 4, 8, 16 and 32 times the attack time and thresholds range from +22dB to –10dB in 1dB steps. If the automatic limiter time constant option is in use, all limiter screens will say ‘automatic’... -
Page 23: Delay Screen
8.4. Delay Screen Delay = 1.003mS Each output has an independent delay time control. This can be adjusted in 2.6 s steps and in 1ms steps giving complete control over driver time alignment. Input delay (base delay) is adjustable in 1ms steps only. To adjust the delay settings: Select relevant channel by pressing the channel ‘GAIN’... -
Page 24: Gain Screen
8.6. Gain Screen O/P1+3 Gain = 0.1dB Each output and input has an individual gain screen. The outputs have a range of +15dB to –40dB, adjustable in 0.1dB steps and the inputs have a range of +6dB to –40dB, again adjustable in 0.1dB steps. To adjust the gain: Select relevant channel by pressing the channel ‘GAIN’... -
Page 25: Menu Options
9. Menu Options 9.1. X-over Sub-Menu Press 'MENU' and select X-over Sub-menu using the ‘BACK’, ‘NEXT’ and 'ENTER' keys. Four options are available in this sub-menu which are: Load a Xover : Loads a stored crossover. This includes factory preset files. Updates can be obtained from your distributor or from the Tannoy website, www.tannoy.com Design a Xover: Opens a wizard to design a crossover. -
Page 26: System Sub-Menu
including all menus. Changes + view: This option locks all parameters and the viewing of them on the LCD including all menus. Changes + mutes: This option locks all parameters, including all menus, and disables all mute keys. Everything: This option locks all parameters and the viewing of them, including all menus, and disables all mute keys. -
Page 27: Aes / Ebu Sub-Menu
when downloading new presets). 9.6. AES / EBU Sub-Menu Connection of AES/EBU signals is via the existing rear panel XLR connectors. Menu Selections: With the AES/EBU option fitted, AES Receive and Diagnostic modes are provided. -
Page 28: Equalisation Curves
10. Equalisation Curves Figure 1 - Parametric filter gain curves. Figure 2 - Parametric filter 'Q' curves. Figure 3 - Parametric filter High and Low shelf curves. - Page 29 Figure 4 - High pass filter curves. Figure 5 - Low pass filter curves. Figure 6 - Parametric filter with high 'Q' to achieve notch response.
-
Page 30: Specifications
11. Specifications Inputs Impedance CMRR Outputs Source Imp Min. Load Max. Level Frequency Resp. Dynamic Range Distortion Maximum Delay Output gain Input gain Parametric Equalisation Filters Filter gain Centre frequency Filter Q / BW (Sections switched to shelving response) Low frequency High frequency Shelf gains High and Low pass Filters... -
Page 31: Operating Notes
With any audio signal processing equipment it is necessary to ensure adequate signal level is used through the device, to avoid sacrificing noise performance. The TDX2 features a menu selectable choice of operating levels to reduce this problem (see section 8.6) It is suggested that the operating level chosen should give adequate level to just light the -6dB LED on the headroom meter with maximum program level being used. -
Page 32: Warranty
13. Warranty No maintenance of the TDX2 is required. If servicing is required, it must only be carried out by qualified personnel. Do not remove the top cover, as there may be a risk of electric shock. All Tannoy electronic components are guaranteed for a period of one year from the date of shipment, subject to the absence of, or evidence of, misuse, overload or accidental damage. -
Page 33: Appendices
14. Appendices 14.1. Appendix 1 : Limiter threshold Limiter threshold in dB to Vrms lookup table. Calculation: Vrms = 0.7746 x 10 ^ (dBu / 20) Vrms 9.75 8.69 7.75 6.90 6.15 5.48 4.89 4.36 3.88 3.46 3.08 2.75 2.45 2.18 1.95 1.73... -
Page 34: Appendix 2: Default Xover Settings
14.2. Appendix 2: Default Xover Settings Default X-over settings and names for all formats. X-over Output 1 Output 2 2x2 way+Ms 120Hz – 1k82Hz 1k82Hz – 22kHz 120Hz – 1k82Hz 1k82Hz – 22kHz 24.8Hz – 120Hz <10Hz – 22kHz 2 x 3 way 22.1Hz –... - Page 36 Tannoy Preset Parameters and the latest downloadable preset files are available from your Tannoy distributor or from our website: Tannoy Limited, Professional Division, Coatbridge, Strathclyde, ML5 4TF, Scotland. Tel: +44 (0) 1236 420199 Fax +44 (0) 1236 428230 e-mail: prosales@tannoy.com Tannoy / TGI North America Inc., 335 Gage Avenue, Suite 1, Kitchener, Ontario, Canada N2M 5E1.
