eeeBOX-U
eBOX-U
Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eBOX-U and is the answer not in the manual?

Questions and answers

Related Manuals for Datoptic eBOX-U

Summary of Contents for Datoptic eBOX-U

  • Page 1 Manual...

  • Page 2: Table Of Contents

    MANUAL Ver 1.0 【Contents】 Introduction ------------------------------------------------------------------- 2 Safe Precaution -------------------------------------------------------------- 2 Features ------------------------------------------------------------------------ 3 Specification ------------------------------------------------------------------ 3 System Requirement ------------------------------------------------------- 4 Installation --------------------------------------------------------------------- 5 Function ------------------------------------------------------------------------ 11 Auto Power -------------------------------------------------------------------- 13 Partitioning & Formatting ------------------------------------------------- 14 Trouble Shooting ------------------------------------------------------------- 21...

  • Page 3: Introduction

    【Introduction】 Thank you for choosing eBOX-U. It is an easy-to-use storage that allows a dedicated approach to storing a data. 【Safe Precaution】 Please read the safe precautions carefully before you using eBOX-U. Ensure that you use the product correctly according to the procedure described in this guide.

  • Page 5: Installation

    Computer model IBM PC/AT Compatible, Power Macintosh, PowerBook, iMac Windows 2000, Windows XP, Mac OS 9.0 or higher Interface Can’t operate properly under Windows 95/ Windows 98SE/ Windows 3.x/ WindowsNT/ Windows ME Please be noted the following product may run irregularly which are not under warranty.
  • Page 6 Connect with S-ATA hardware drive. Please make sure you connect properly。 ‧If only install one HDD, please set S-ATA covert adapter as Master. ‧ If connect two S-ATA HDD ，Please set second S-ATA convert adapter as SLAVE。...
  • Page 7 Fasten HDD with screws 3：Unfasten the screws on the back of the TERA TOWER。 4：Remove left side panel...
  • Page 8 When install two or more HDD，set upper HDD us Master and lower HDD as Salve. Please refer to the diagram. 5：Remove front panel，and pull out the AC cable and flat cable。Insert HDD in trun from up to down. 6：Press the rubbers on each side to fasten the HDD...
  • Page 9 7：Connect AC cable and flat cable to HDD。 Please connect properly incase of any damage. AC cable Flat Cable 8：Fasten left side panel.
  • Page 10 Power on and off Power ON Press once, power will turn on Power OFF Press power for 3 seconds ※If auto power effective, Tera tower will automatically on when PC operating.
  • Page 11 ■ Sleep Mode Sleep button ‧ Press sleep button for 3 seconds, HDD and Fan will stop operating and Sleep Mode LED light will be off. ‧If data was been stored to one of HDD, the Sleep Mode LED light will be off. ※...

  • Page 12: Function

    4 Combine × 2 8 Combine mode 1.5TB 1.25TB 1.75TB PC setting PC Setting If you wish to set up combine model by driver, please make sure the setting is correct. You can simply download driver from our website. www.datoptic.com...
  • Page 13 2 Combine × 4 mode 4 Combine × 2 mode 8 Combine mode PC setting PC Setting If you wish to set up combine model by driver, please make sure the setting is correct. You can simply download driver from our website. www.datoptic.com...

  • Page 14: Auto Power

    【Auto power setting】 Switch power button on the back to “effective”, auto power mode is setting. When PC operating, Tera Tower will automatically on.

  • Page 15: Partitioning & Formatting

    ■ Partitioning & Formatting Please be aware that this will destroy all your existing data on the drive, so make sure you have backup! This step is usually only required the first time you install the HDD or you have a factory new HDD.
  • Page 16 ■ Disk partition If HDD shows “unallocated”, the HDD is not formatting. Click the right button of mouse and open the window, select〈New Partition〉 〈Welcome to New Partition Wizard〉 Click〈Next〉...
  • Page 17 〈Select Partition Type〉 Select〈Primary Partition〉 Select〈Next〉 〈Specify partition size〉 Select〈Next〉 〈Assign Drive Letter or Path〉 Select 〈Assign the following drive letter “M”〉...
  • Page 18 Appear〈Format Partition〉 」windows。 Please follow the Partition Wizard to set up. When all sets，Click〈Next〉 〈New Partition Wizard Finish〉 click〈Finish〉 【Modify and detach HDD since PC is running】...
  • Page 19 【Unplug Procedure】 Single click right mouse button on the taskbar icon. Use Windows of〈Safely remove hardware〉 Click〈Hardware Device〉twice Select〈mass memory storage device〉 select〈STOP〉 Stop a Hardware Device and click〈OK〉 Appear〈Save to remove hardware〉window , click〈OK〉...
  • Page 20 ※If install 2 or more HDD during standard mode, when remove one of HDD, others will be deleted. Warning To assure no data will be lost, always follow the unplug procedure. If not, data could be lost and the following message will show up!!
  • Page 21 ※「Disk Utility」located at application＞ Utility。 It shows that can be formatted disk summary On the left side。 eBOX-U shows「xx GB Century」 〈xx as the connected HDD capacity〉 。 Click any of eBOX-U。 Shows the connected disk information。 Click the upper「パーティション〈Partition〉 」...
  • Page 22 Formatting ：Select the disk the you want to format。Like: Mac OS Standard、Mac OS extend、 UNIX file management system、free capacity，please select Standard Mac OS Standard or Mac OS extend。 Size ：Can change the desire for making size of the Volume。 Option ：Make sure install the MacOS9 driver, then it will be install in driver of MacOS9。...

  • Page 23: Troubleshooting

    【Troubleshooting】 Explain how to solve the most common error。 Can not recognize Make sure all cables and AC cord has been connected properly Make sure power LED light is on. Make sure HDD、S-ATA convert adapter setup properly。 Can not operate OS Don’t support OS operation。...
  • Page 24 Disclaimer All information in this document is subject to change without prior notice. The manufacturer makes no representations or any warranties regarding the contents of this manual. The information contained in this manual is provided for the general use by the customer. No part of this document may be reproduced or transmitted in any form by any means without the express written permission of the manufacturer.
