- Page 1 Explo Zündtechnik RX-1K Manual v0.1 As of September 2013 Explo Zündtechnik Harald Kulterer Völkermarkterstrasse 240 9020 Klagenfurt am Wörthersee Austria Tel: +43 (0) 463 / 32 2 45 Fax: +43 (0) 463 / 32 2 45 75 Mobil: +43 (0) 664 / 51 007 51 www.explo.at...
- Page 2 Note: This Manual is a pre-version. If you have any questions, or should any vagueness appear, which this manual cannot answer, please do not hesitate to contact us either by phone, or by E-Mail. We wish you a lot of fun and success with your Explo-Ignition System! ~ The Team of Explo IGNsystems...
-
Page 3: Table Of Contents
Socket for Igniters......................5 2.2.3 Socket to switch on an programm................... 5 2.2.4 Display window with status LEDs ..................6 Using the RX-1K ..........................6 Activation..........................6 Switching off ..........................6 Controling the Receiver ......................7 Programming ........................... 7 Software and Drivers ....................... 7 Using the Steppersoftware ...................... -
Page 4: Overview/Description Of Components
2 Overview/Description of Components 2.1 Overview of Components Antenna Status-LEDs Socket to switch on and Socket for igniters programm... -
Page 5: Description Of Components
1 2 3 4 5 The 5 pole socket of the RX-1K is used to turn on the device and also to program it, as well as supply it with an external power source. To activate the device, Pin 1 and 2 (see picture above) must be connected. -
Page 6: Display Window With Status Leds
Channel is connected LED off Channel open 3 Using the RX-1K 3.1 Activation To switch on the device, use the supplied 2 pole terminal block with attached cable. This terminal block is attached to Pin 1 and Pin 2 of the programming socket (see 2.2.3). -
Page 7: Controling The Receiver
Device. When used in a show, it can be programmed using the "RX send show" command. Please read through the RX/TX-manual of the X2-series for more information. 4 Programming 4.1 Software and Drivers Box- and Channelnumber of the RX-1K can be programmed using the current Version of the Steppersoftware. find download... -
Page 8: Other Functions Of The Steppersoftware
All further fields of the steppersoftware, have no use with the RX-1K. 4.2.1.4 Special field opening time The Field of Channel 69 is a special case. It allows you to set the opening time of the RX-1K in seconds. 4.2.2 Other Functions of the Steppersoftware New: Create a new template Edit: Edit the selected template. -
Page 9: Transmitting Data To The Receiver
4.2.3 Transmitting data to the receiver To program the receiver, it must be connected to the PC by use of the Steppercable and its Adapter, or the Bootloadercable in case of the X2-series. Before programming, the device must be switched off. -
Page 10: Usage
6 Usage 6.1 Radio connectivity A good radio connectivity is an essential part of having a good performance when using wireless ignition systems. Taking note of a few simple hints can drastically increase the connectivity between Transmitter and Receiver. 6.1.1 Overview of Radio wave propagation: Radio waves are electromagnetic waves, flowing with near light speed (~300.000km/s) .
