Summary of Contents for Virtue SPIRE III

  • Page 1 ™ PAINTBALL LOADER BUILT TO WIN SPIRE III MANUAL...
  • Page 2: Quick Setup

    III loader. It is recommended you read the whole manual as it contains important product and safety informa- tion. QUICK SETUP SPEC LENGTH: 9.5” To start using the Spire III ™ immediately install 3 AA batteries. The LED indicator shows the following information during normal operation. WIDTH: 4” • BLUE, loaded and ready.
  • Page 3: Operation

    SOUND By default, the Spire III is muted. To turn on the speaker, with the Spire on, simply hold in the Force Feed button for 2 seconds. The Spire will beep the number of times the Reload Indicator Alarm is set to confirm you have turned on the Speaker.
  • Page 4: Low Battery Indicator

    Always recycle used batteries according to the manufacturer’s instructions. There is a built in Low Battery Indicator (LBI) on the Spire III. When turning on the Spire III with good batteries the LEDs will turn to either red or blue depending if you have paint inside the loader or not. If the batteries are low you will hear 3 short beeps and LED will stay solid yellow for 3 seconds.
  • Page 5: Battery Life

    PROGRAMMING MUTE BUTTON The button on bottom of Spire III serves several functions. When the Spire III is on, it serves as an electronic force feed button. Pressing the button causes the loader to feed forward. When you hold the Force Feed button in for 2 seconds, it unmutes or mutes the speaker. The Spire III is muted by default and remembers your previously saved setting.
  • Page 6: Removing Lid

    ™ OPENING SHELL To open the Spire III shell simply press the lock button on the back of the Spire III. The top shell is spring loaded and will automatically lift up to the open position. To close just press down until there is a click sound.
  • Page 7 There is no particular maintenance needed for the Spire III. Keeping it clean and using fresh batteries is all that is required. If you leave the Spire III unused for more than 6 months it is suggested to remove the batteries to avoid damage due to a possible leaking battery.
  • Page 8: Programming Settings

    Force Feed button for 2 seconds. The Spire will beep the number of times the Reload Indicator Alarm is set to confirm you have turned on the Speaker. The Spire III will remember your setting next time you turn on the Spire.
  • Page 9 Spire will change their color to Indicate when it's time to reload. Use this setting in conjunction with the Reload Indicator Alarm to fine tune how you want the Spire III to warn you to reload based on your style of play.
  • Page 10 Do not adjust this setting unless there is problem with your Spire III, and you have already removed and cleaned the Spire Drive and are sure you have good batteries. If the Spire III stops spinning before the balls stack is full, you can raise this setting. Too high of a setting can cause unwanted pop corning, and too low of a setting can cause the Spire III to stop spinning too soon.
  • Page 11: Firmware Upgrade Mode

    LED will turn White. The loader is now Discoverable on the mobile application. If left in Discover mode too long the Spire III will automatically reboot and exit the programming menu. Start the application and press Upgrade Firmware. The app will show a your loader's serial number in the list.
  • Page 12: Troubleshooting

    Make sure the LED and Speaker are turned on in the program menu, or perform a factory reset. SPIRE III FEEDING SLOWL Y OR ERATICALL Y Ensure that your batteries are fresh and a good quality. Off brand batteries frequently cause poor performance.
  • Page 13 ™ SPIRE III IS POPCORNING OR PULSING WHEN FULL Ensure that your batteries are fresh and a good quality. Off brand batteries frequently cause poor performance. Ensure that you have the latest firmware update by using the Spire App to download and flash your Spire III.
  • Page 14 ( 2 ) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: SH6MDBT40 MADE IN TAIWAN USA Office Europe Office Virtue Paintball Virtue Paintball ,LLC GmbH 40-14 Oser Ave Wienerstrasse 42 / 2...
