SAC UMAC S24.0 Instruction Manual

Professional amplifier, class-d technology
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UMAC S24.0 and is the answer not in the manual?

Questions and answers

Related Manuals for SAC UMAC S24.0

Summary of Contents for SAC UMAC S24.0

  • Page 2: Before Use

    Welcome Welcome you from management and staffs of SOVICO PROFESSIONAL. All of the staffs here at SOVICO PROFESSIONAL have dedicated to provide excellent products of value, and we are glad that you have purchased one of our products. We sincerely trust that this product will provide satisfactory service, but if anything goes up you do not satisfy completely, we will endeavor to make things right.

  • Page 3: Safety Instruction

    Safety Instruction 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.

  • Page 4: Installation

    Professional Ampli er Component Professional Amplifier powerCON TRUE1 User Manual (1pcs) Power Cord 1.5m (1pcs) 12pins Terminal Block (4pcs) LAN Cable 2m (1pcs) (S8.4 only) Rack Mounting Screws (4pcs) Washer (4pcs) Installation 1.1 Rack System (S24.0, S8.4, S2.5) 1. Use the included rack mounting screws to secure the amplifier in the rack as shown. 2.
  • Page 5 Professional Ampli er Front Panel and functions [Front Panel] S24.0 S8.4 S2.5 1. PWR If the Switch of the rear panel is ON, the blue LED will light up and AMP will enter the operating state. 2. STBY If the Switch on the rear panel is OFF and the AC Cord is connected, the red LED lights up and the AMP go into standby mode. 3.

  • Page 6: Power Switch

    Professional Ampli er Rear Panel and Functions [Rear Panel] S24.0 S8.4 S2.5 1. Power Switch It is a switch to supply power. When it is pressed up, Power LED will light up and the device will operate. 2. NMS By connecting the PC through the Network, you can monitor the AMP status. 3.
  • Page 7 Professional Ampli er Rear Panel and Functions 4. LOOP OUT/LOOP IN This function is for connecting two or more AMPs and it is useful when multiple AMPs are used together with the same input signal. ※ S24.0: Use DSUB-25PIN cable for LOOP OUT/LOOP IN. S8.4: Connect the cable to the provided Terminal Block according to the channel.
  • Page 8 Rear Panel and Functions 5. Speaker Output Terminal to the figure below for specifications of signals output from the output terminal for each mode. ※ S24.0: In Bridged Mono Mode, must connect CH3, 4(BRIDGE) and CH5, 6(BRIDGE), and must not connect cables to CH3, 4 and CH5, 6.

  • Page 9: Level Adjust

    Professional Ampli er Rear Panel and Functions 6. Level Adjust A volume for level adjustment is provided for each channel. The potentiometer’s operational range is 0 dB to minus infinity in 20 steps. Attenuation is logarithmic, with -13 dB at the 12 o’clock position. See table for levels at other increments.
  • Page 10 Professional Ampli er Rear Panel and Functions 8. Link Switch (STL : See To the Left) Place the switch to the right to set Link Mode. The input signal on the left is input to the right input channel as well. It is very convenient to use the same input signal on several channels together.

  • Page 11: Computer Requirements

    1.2 Computer Requirements The NMS, which is dedicated software for the SAC S-series Amp, can be installed on PC and MAC. The specifications applicable to NMS are as follows. Before installing the software, check the computer virus and install the software.

  • Page 12: Network Settings

    Professional Ampli er 1.4 Network Settings Network configuration is required to monitor the SAC S-series Amp with PC, MAC. The network setup for the SAC S-series Amp is easy and simple. Follow the procedure below. 1.4.1 Static IP 1.4.2 DHCP IP (Use Switcher or router) 1.
  • Page 13 Professional Ampli er 1.5 NMS Monitor NMS Monitor can monitor SAC S-series Amp’s Title, Model Name, Network Connect, Find a Location, Audio Signal, Clip, Protection, Temperature, etc. 1. Title : You can edit the Title name. Sort by title name.

  • Page 14: Network Setup

    Professional Ampli er 1.6 Network Setup Network Setup allows you to set the network mode of the SAC S-series Amp. The network mode setting allows DHCP and Static IP settings. The basic network is DHCP IP con guration. 1.6.1 Static IP 1.6.2 DHCP IP...
  • Page 17 AC INPUT 220~230V/50~60Hz...
  • Page 18 AC INPUT 220~230V/50~60Hz...
  • Page 19 AC INPUT 220~230V/50~60Hz...

  • Page 22: Service And Warranty

    Service and Warranty TO PURCHASE ADDITIONAL SOVICO PROFESSIONAL. GEAR AND ACCESSORIES To purchase SOVICO PROFESSIONAL gear and optional accessories, contact any authorized SOVICO PROFESSIONAL distributor. For a list of SOVICO PROFESSIONAL distributors please visit our website at www.sovicopro.com. SERVICE AND REPAIR For replacement parts, service and repairs please contact the SOVICO PROFESSIONAL distributor in your country.

This manual is also suitable for:

Umac s2.5Umac s8.4
