Summary of Contents for Sioux Chief StreamLine
- Page 1 INSTALLATION GUIDE StreamLine Linear Drain With Full Mortar Bed Adapter Kit Supply Drainage Support www.siouxchief.com...
- Page 2 Flashing from FreeStyle Flashing from FreeStyle Select outside corner CPE. Outside Corners Linear Drain StreamLine Linear Drain is purchased separately from the Full Mortar Bed Adapter Kit. Linear Drain material to match Shower ordered separately. Pan Liner material, PVC or CPE.
- Page 3 Follow manufacturers instructions. Use products 1-1/4" 2-1/4" recommended for the type of sloped bed being installed. StreamLine Linear Drain assembly is intended to install tight 24" 15-3/4" to toe plate and studs within shower PRIOR to installation of mortar bed, backer board, waterproofing and tile.
- Page 4 Installation Guide 1. Wall Preparation 3. Waste Pipe Blocking Option A: Waste Pipe Not Installed. Place, Mark and Cut Blocking between studs may be needed for Shower Pan Place drain base in desired location on sub floor. Mark Liner attachment prior to drain installation. waste pipe location on sub-floor.
- Page 5 Installation Guide 4. Preparation for Pre-Sloped Bed Option B: Waste Pipe Pre-Installed Dry fit drain base over location of existing waste pipe. If location does not allow drain base to fit flush against at Mark Bed Slope least 2 shower walls, move location of plumbing to allow 1/4"...
- Page 6 Installation Guide 5. Fasten Drain Base to Sub-Floor B. Install Drain Base to Waste Pipe and Sub-Floor Caution: Confirm proper plastic pipe primer and cement for drain base For Concrete Sub-Floor A & B type (PVC or ABS). Check drain base label to confirm. For Wood Sub-Floor B only Apply appropriate plastic pipe primer and cement to drain and waste pipe following local plumbing codes...
- Page 7 Installation Guide 6. Sloped Mortar Bed Installation 7. Prepare Shower Pan Liner Protect Drain Base. Apply tape over entire top surface of drain base. Option 1: For Drain at Back Wall Install Sloped Bed. Follow industry standards to complete sloped mortar Shower Pan Liner must turn up the walls a minimum bed installation.
- Page 8 Installation Guide Inside Shower Option 2: For Drain at Full Curb Entry Shower Pan Liner must turn up the walls a minimum of 3" above finished shower curb and 6" above floor in Outside Corners showers without curbs. Under Liner 6"...
- Page 9 Installation Guide 7. Prepare Shower Pan Liner Making Corners (cont.) Tucked Corner (when space is available between studs) Fold and crease to size. Tuck Shower Pan Liner into Option 3: space between studs. For Drain at Partial Width Curb Shower Pan Liner must turn up the walls a minimum of 3"...
- Page 10 Installation Guide 7. Prepare Shower Pan Liner (cont.) 8. Secure Shower Pan Liner A. Seal Drain Base Lift out Shower Pan Liner. Remove tape, leaving tape Option 4: over drain hole only. For Drain in Center of Floor Apply a 1/8" continuous bead of NobleSealant 150 Shower Pan Liner must turn up the walls a minimum around chamfer on base flange and another bead in of 3"...
- Page 11 Installation Guide 9. Fasten Shower Pan Liner 11. Cut Out Flashing Nail through top 1" of Shower Pan Liner to studs With a razor knife, carefully trim out Shower Pan Liner and/or blocking. from center of collar. Remove tape from drain hole. Caution: Do not puncture Shower Pan Liner outside of collar.
-
Page 12: Install Brackets
Installation Guide 14. Install Brackets 16. Install Mortar Guard Align holes in Bracket with second set of holes in from Install Mortar Guard over Foam Block and Brackets. end of drain base. Attach using two 1/2" screws. Center end to end over Clamping Collar. Fully seat Repeat for opposite end of drain base. - Page 13 Installation Guide 18. Remove Foam Block and Brackets 20. Install Pre-Strainers Carefully remove Foam Block. Remove Bracket Screws Place short leg of Pre-Strainer down, facing drain hole. and Brackets. Install 1/2" pan head screw, align strainer and tighten screw. Repeat for opposite strainer. Note: On 24"...
- Page 14 Installation Guide 22. Temporarily Attach Strainer 24. Adjust Strainer Height Remove strainer. Remove tape from strainer. If factory Note: Strainer attachment holes are not symmetrical. If screws do not align with holes in drain base, turn strainer end-to-end. installed film, start peeling at one end of strainer. Peel side to side (sawtooth pattern) to other end of strainer.
- Page 15 Installation Guide Cleaning Drain Re-Attach Strainer Note: Strainer attachment holes are not symmetrical. If screws do not To clean drain, remove 3 screws in top of strainer. Clear align with holes in drain base, turn strainer end-to-end. any hair or other obstructions from drain. Place strainer over height adjustment screws.
- Page 16 PMG 1065 File No. 7249 www.siouxchief.com B.2/18 #IS-823FMB STREAMLINE FMB INSTALLATION INSTRUCTIONS...
