- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Kollmann SeeSnake FlatPack ® and Color FlatPack SeeSnake ® Diagnostic Equipment SeeSnake ® FlatPack and Color FlatPack Record Serial Number below and retain product serial number which is located on nameplate. Serial No.
-
Page 2: Table Of Contents
Kollmann SeeSnake ® FlatPack and Color FlatPack Table of Contents Recording Form for Machine Model and Serial Number ...................1 General Safety Information Work Area Safety ................................2 Electrical Safety................................2 Battery Precautions ..............................2 Personal Safety ................................2 Tool Use and Care ..............................3 Service ..................................3 Specific Safety Information Equipment Safety ................................4 Description, Specifications and Standard Equipment... -
Page 3: Work Area Safety
Kollmann SeeSnake ® FlatPack and Color FlatPack General Safety Information Minimum Wire Gauge for Extension Cord Nameplate Total Length (in feet/meters), CAUTION! Read and understand all instructions. Failure Amps Gauge (in AWG/mm to follow all instructions listed below may 0 - 25/0 - 8 26 - 50/8 - 15 51 - 100/15 - 30 result in electric shock, fire, and/or serious... -
Page 4: Tool Use And Care
• Provide proper cleaning. Unplug this product from the Tool Use and Care wall outlet and remove battery before cleaning. Do • Always transport the SeeSnake FlatPack with the not use liquid cleaners or aerosol cleaners. Use a Monitor Shield closed. This prevents product damage. -
Page 5: Specific Safety Information
LED Window – The donut shaped window that covers and protects the LEDs from abrasion. The SeeSnake FlatPack drum is a UL Listed accessory, in- tended for use only with the following UL Listed SeeSnake Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176... -
Page 6: Drum
Kollmann SeeSnake ® FlatPack and Color FlatPack Spring Assembly – Flexible stainless steel spring and as- sociated components that hold the camera to the push cable. It provides a flexible transition from camera to push cable, and protects the terminations within the spring. In Line Transmitter –... - Page 7 Kollmann SeeSnake ® FlatPack and Color FlatPack LED Indicators (Figure 7) – The LED indicators above Red Multifunction Button (Figure 6) – This button serves the following functions: the monitor screen indicate the following operational conditions: • Press and quickly release to turn the system power •...
-
Page 8: Specifications
Kollmann SeeSnake ® FlatPack and Color FlatPack Specifications Place the drum so the push cable is easy to manage as you push the camera through the line. Two to three feet ″ to 4″ (38 to 102 mm) Line Capacity....1 (about one meter) from the access point is usually the op- Max. -
Page 9: Operation
Kollmann SeeSnake ® FlatPack and Color FlatPack NOTE! The Monitor Pack will not recharge the battery; Guide Socket Guide Pin the battery must be removed from the Monitor Pack for recharging. Use only the charger spec- ified by the battery manufacturer! Unwrap the Interconnect Cord from its holder on the drum and plug its connector into the matching SeeSnake System connector on the Monitor Pack. -
Page 10: At The Job Site
Kollmann SeeSnake ® FlatPack and Color FlatPack When the Interconnect cord is NOT plugged into the Monitor Pack, the Video In/Out jack functions as a Video In jack. An RCA cable can be used to connect this jack to the “Video Out” jack of a VCR for reviewing a recording you have made. -
Page 11: Transportation & Storage
Kollmann SeeSnake ® FlatPack and Color FlatPack NOTE! See the Video Tape that came with your system Do not clear obstructions with the camera head! for valuable Tips and Tricks on how to handle This may cause premature failure to your camera different situations. -
Page 12: Centering Guides
Kollmann SeeSnake ® FlatPack and Color FlatPack Centering Guides Installing the SeeSnake ® Star-Type Centering Guides Centering guides can improve the picture by bringing the camera closer to the pipe’s center, allowing the camera to see an equal amount of the pipe wall in all direc- tions. -
Page 13: Removing Star-Type Centering Guides
Kollmann SeeSnake ® FlatPack and Color FlatPack Installing the SeeSnake ® Compact, and easiest if you place the closed portion of the c-ring FlatPack Ball-Type Centering Guides into the groove and work toward the open end. See Figure 22. Ball-type centering guides consists of two halves that are pre-assembled at the factory, and two steel clips that hold the guide in place on the spring. -
Page 14: Maintenance And Cleaning
Kollmann SeeSnake ® FlatPack and Color FlatPack they may wear on these components. Stir in a bucket of warm water and mild detergent to flush the spring area. NOTE! Never use a water jetter to clean the spring as- sembly. If a spring takes a set during storage, dip it in hot water to straighten. -
Page 15: Service And Repair
Kollmann SeeSnake ® FlatPack and Color FlatPack Service and Repair CAUTION Tool should be taken to a RIDGID Independent Authorized Service Center or returned to the factory. All repairs made by Ridge service facilities are warranted against defects in material and workmanship. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 FAX 781.665.0780 - TestEquipmentDepot.com Ridge Tool Company...
