Summary of Contents for Maestrogen Ultra Slim LED Illuminator
- Page 1 UltraSlim LED Illuminator Instruction Manual Catalog Number SLB‐01 Version 01_10 www.maestrogen.com ...
- Page 2 WARRANTY The LED illuminator is warranted against defects in materials and workmanship for 1 year. If any defects occur in the instrument or accessories during this warranty period, Maestrogen will repair or replace the defective parts at its discretion without charge. The following defects, however, are specifically excluded: 1. Defects caused by improper operation. 2. Repair or modification done by anyone other than Maestrogen or an authorized agent. 3. Damage caused by substituting alternative parts. 4. Use of fittings or spare parts supplied by anyone other than Maestrogen. 5. Damage caused by accident or misuse. 6. Damage caused by disaster. 7. Corrosion caused by improper solvent or sample. For any inquiry or request for repair service, contact your local Maestrogen office. ...
- Page 3 Maestrogen is not responsible for any injury or damage caused by the use of this instrument for purposes other than those for which it is intended, or by modifications of the instrument not performed by Maestrogen or an authorized agent. ...
- Page 4 1. The instrument must be placed on a bench leaving at least 10 cm of space all around in order to avoid any obstacle that may reduce the ventilation. 2. Connect the instrument to the power using the annexed cable. The power font must be able to deliver at least 250 VA with a voltage between 100 and 240 Vac. The plug must have a ground connection. The adaptor supplies 24 V DC voltage. Installation with the Standard Documentation System: This instrument has been designed to work with the Standard Documentation System. In this case follow the instructions included in the Standard Documentation manual or any other instrument that will be released in the future. GENERAL PRECAUTIONS ∙ Plug the illuminator on an electric line with ground connection. ∙ The illuminator is equipped with thermal protection to prevent overheating. ∙ Do not pour liquids directly on the illuminator. www.maestrogen.com ...
- Page 5 Press the ON/OFF switch to ON. The LEDs within the unit will begin glowing upon the glass support. After viewing the sample or cutting out the bands, turn the illuminator off. General Appearance of the LED illuminator www.maestrogen.com ...
- Page 6 Front Panel of the LED illuminator Rear Panel of the LED illuminator Adaptor: 24V DC / 1 A Power AC input: 100~240 V; 50/60 Hz power source www.maestrogen.com ...
- Page 7 TECHNICAL SUPPORT Maestrogen offers technical support for all of its products. If you have any questions about the product’s use or, operation, please contact Maestrogen at the following info. 1450 Sutter St. #518 San Francisco, CA 94109, USA Phone: +1‐415‐5956658 E‐Mail: info@maestrogen.com www.maestrogen.com ...
