YLI YM-180M Manual

Mortise Mount Magnetic Lock Manual
Specification
MODEL SIZE(UNIT:MM)
YM-180M 190Lx32Wx22.5H
YM-180M-S 190Lx32Wx22.5H
YM-280M
232Lx42Wx24.5H
YM-280M-S 232Lx42Wx24.5H
YM-350M
273Lx44Wx28H
YM-350M-S 273Lx44Wx28H
YM-500M 254Lx65.8Wx39H
YM-500M-S 254Lx65.8Wx39H
Installation
For example: YM-350M (Unit:mm)
45
11
10
190
Armature plate
33
( 1 ) D i g t h e h o l e
NOTE:
!
Please Read Specification Before Attempting To Install Magnetic Lock
A. Handle the equipment with care, damaging the mating surfaces of the magnet or armature plate
may reduce locking efficiency.
B. The magnet mounts rigidly to the door frame. The armature plate mounts to the door with hardware.
Kit provided that allows it to pivot about its center to compensate for door wear and misalignment.
C. Template must take place with the door in its normally closed position.
D. Please tuist screws of magnetic lock firmly
E.Detect signal of Door stute:The Limit of Dry reed and Dry contact is 0.5A/30VDC,Don,t overload.
www.yli.cn
VOLTAGE
12/24VDC
12/24VDC
12/24VDC
12/24VDC
12 D V C
( 24VDC need order)
12 D V C
( 24VDC need order)
12/24VDC
12/24VDC
The hole 14.0X2
The hole 9.0X2
Optional
Door
( 2 ) F i x s c r e w s
CURRENT
HOLDING FORCE
12V/300mA
180kg(350Lbs)
24V/150mA
12V/300mA
180kg(350Lbs)
24V/150mA
12V/500mA
280kg(600Lbs)
24V/250mA
12V/500mA
280kg(600Lbs)
24V/250mA
12V/480mA
350kg(800Lbs)
24V/240mA
12V/480mA
350kg(800Lbs)
24V/240mA
12V/420mA
500kg(1200Lbs)
24V/210mA
12V/420mA
500kg(1200Lbs)
24V/210mA
28
226
257
28.9
44
( 3 ) D i g t h e h o l e
We create security
R
EMC
tested
Germany
DOOR
Single Door
Single Door
Single Door
Single Door
Single Door
Single Door
Single Door
Single Door
( 4 ) F i x s c r e w s
