Elko ZTR-10 Manual

Manual
Device is designed for 1-phase AC 230V connection and must be installated according standard valid in the existing country. Connection according to the details in this direction.
Installation, connection, setting and servicing should be installed by qualified electrician staff only, who learn this instruction and functions of device. For right device protection
should be fronted-end certain element. Before starting installation must be main switch in position "SWITCH OFF" and device should be out of voltage. Don´t install device to
suppliers surcharge electro-magnetic interference. By right installation of device is provide good air circulate to don´t pass maximal operating temperature,in case of higher
ambient temperature and permanent working. For installation and setting use screw-driver cca 2 mm. The device is full-electronic - installation should be effected according to this.
Function without problems is too dependent on previous type of transportation, storing and manipulation. In case of any vestige of destruction, deformation, non-function or missing
part, don´t install and made claim to seller. Product may be, after passing operating time, disassembled, recycled or puted on protected tip.
Description
ZTR-10
AC 230 V
50 Hz
U
PRI
4V
Output voltage AC 12 V
Examples of usage
L
N
ZTR-10
AC 230 V
50 Hz
U
PRI
4V
12V
4VA
Bell transformer
EN
ZTR-10
167-02-001 Rev.: 0
Supply terminals
ELKO
8V
Output voltage AC 4 V
12V
4VA
Output voltage AC 8 V
8V
Characteristic
- Supply: AC 230 V
- Universal power supply with AC output voltage
- Short-circuit resistant
- General usage - e.g. supply of door bells, electric locks, etc.
- Output voltage: AC 4 - 8 - 12 V
- Double output terminals
- 3-MODULE, DIN rail mounted
Technical parameters
Supply voltage:
Supply voltage tolerance:
Consumption without load:
Consumption with load:
Output voltage:
Max. load:
Output voltage-no load AC:
Fuse:
Operating temperature:
Storing temperature:
Max. testing voltage:
Protection degree:
Max. cable size:
Weight:
Dimensions:
Standards:
Connection
U
PRI
4V
Tovarni 1613, Holesov 769 01, Czech Republic
ELKO
Tel.: + 420 573 395 114-115; Fax: + 420 573 399 160
Informations about this products you can find on:
www.elkoep.cz/ztr10e.htm
ZTR-10
AC 230 V / 50 - 60 Hz
-15 %; +10 %
AC 1 VA
AC 5 VA
AC 4 V AC 8 V AC 12 V
750 mA 500 mA
5.9 V 11 V
short - circ.resistant
o
-20 .. +50 C
o
-20 .. +60 C
4 kV
IP20/40
2.5 mm 2
343 g
90 x 52 x 65 mm
EN 61010-1; EN 60742
AC 230 V
50Hz / 60Hz
8V
12V
4VA
e-mail: elko@elkoep.com, www.elkoep.com
350 mA
16 V
