Summary of Contents for Villeroy & Boch L200
- Page 1 Montageanleitung Betätigungsplatte L200 Installation instructions Actuating plate Instructions de montage Plaque de commande Instrucciones de montaje Pulsador Istruzioni per il montaggio Piastra di azionamento Montagehandleiding Bedieningsplaat Инструкция по монтажу Кнопка смыва...
- Page 2 Safety Warning! Electrocution from touching live components! Severe injury and even death can be the consequences. • The mains connection must be made exclusively by electricians. • When carrying out work, make sure that the power lead is disconnected from the mains and secured against reconnection.
- Page 3 1. Determination of the installation location for the flush-mounting socket. Our recommendation, above the flushing tank, see Illustration 1. 2. Installing the flush-mounting socket. 3. Route the included empty tube from the flush-mounting socket to the flushing tank, see Illustration 2. page 8 | 19.01.2016 | www.villeroy-boch.com...
- Page 4 Mount the push plate 1. Screw the carrier plate in place. 2. Connect the plug to the socket, see Illustrations 3 and 4. page 9 | 19.01.2016 | www.villeroy-boch.com...
- Page 5 3. Install push plate, see Illustration 5. Cleaning page 10 | 19.01.2016 | www.villeroy-boch.com...
