KITCHEN FAUCET INSTALLATION
THANK YOU FOR CHOOSING FIORE™
If you have any questions regarding your Fiore products please contact your local sales representative or visit www.fiorelife.com/support
for customer support and service information.
Thank you again,
FIORE™
PRIOR TO INSTALLATION
Prior to installation please be sure to review all installation instructions with a licensed or quialified plumbing technician who is familiar
with all local plumbing and building codes in your jurisdiction.
FEATURES
• Brushed Nickel or Polished Chrome Finish
• Solid Brass body and construction
• Single handle lever
• FiORE Temperature Recall. Faucet may be turned on and off at
any temperature setting
• Pull-down extension
• 360 degree spout rotation
• Single-hole installation
SUPPLIED COMPONENTS
• Solid brass kitchen faucet
• Hot and Cold braided steel supply hoses
CODES AND STANDARDS
Meets or exceeds:
• ASME A112.18.1 / CSA B125.1
• ICC/ANSI A117.1
• AB 1953
IMPORTANT
Immediately upon receiving your Fiore product and removing it from its packaging we strongly suggest INSPECTING your
Fiore product for potential freight damage. Any claims for damage visible or hidden, must be made immediately in order for the
carrier to assume full responsibility and absorb any associated costs.
If damage or defect is discovered DO NOT INSTALL your Fiore product. Any claimed damage or defect to the finish of the product
after the product has been installed will be excluded from any manufacturer warranty.
Always shut off your the main water supply before removing the existing faucet and/or installing a new one. Open the hot and cold knobs
on the existing faucet in order to release built up pressure.
• cCUPC
• NSF 61
• CALGreen
FI5001 BNC
SONO
USA / Canada:
www.fiorelife.com
