PHILICAM
PHILICAM
Plasma cutting machine user manual
Jinan Lifan Machinery Co.,Ltd
Website:www.fldcnc.com
Service Contact information :
Email:
Service Skype:
Please send us your Order No. , we will do our best service for you.
济 南 力 帆 机 械 设 备 有 限 公 司
Jinan Lifan Machinery Co.,Ltd
http://fldcnc.en.alibaba.com
service@fldcnc.com
1
lifancnc

Advertisement

loading
Need help?

Need help?

Do you have a question about the PHILICAM and is the answer not in the manual?

Questions and answers

Summary of Contents for Jinan Lifan Machinery PHILICAM

  • Page 1 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd PHILICAM PHILICAM Plasma cutting machine user manual Jinan Lifan Machinery Co.,Ltd Website:www.fldcnc.com http://fldcnc.en.alibaba.com Service Contact information : Email: service@fldcnc.com Service Skype: lifancnc Please send us your Order No. , we will do our best service for you.
  • Page 2 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Customer First Service First Quality First Plasma cutting machine install manual CONTENTS 1. Install machine ………………………………………..page2 2. Adjusting ……………………………………………… page8 3. Maintenance…………………………………….………page13 4. Other point need pay attention………………………….page18...

  • Page 3: Install Machine

    济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Chapter One: Install Machine Thank you very much for your right choice . Safety Plasma Cutting Machine are designed and built with ample safety consideration.
  • Page 4 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd 2.Connect lines in the control box input three phase 380v and one zero wire,blue wire is Connect plasma N zero wire ,three black power ,three phase 380v wire is L fire wire .
  • Page 5 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Cutting Check air Adjust current Arc line Plasma head connector Material holder connector Sign line Photo 2.—Plasma Power connect...
  • Page 6 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Material holder This is holder for material Photo 3- Material holder Attention: * Ground function.Must touch with material when working * This holder can put any place of the material.
  • Page 7 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Exhaust pressure t least 0.8MPa Photo 4—Air compressor power connect Air compressor connect with plasma power Photo 5-Air compressor connector with plasma power...
  • Page 8 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Connect the air compressor Photo 6- Air compressor connect with plasma power...
  • Page 9 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Operating panel Emergency stop Power swith Photo 7 -- Open green button...
  • Page 10 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Main menu U disk,upload the file Photo 8 -- Operating system Attention: If screen show is not English , you can press G G 3 , screen will show as follow ,you...
  • Page 11 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Photo 9-- change English show 3. Set up the parameter Press system...
  • Page 12 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd...

  • Page 13: Adjusting

    济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Adjusting Chapter 2 During work, there need adjust according different material. First step :Adjusting Air Pressure...
  • Page 14 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Air pressure adjusting Air pressure normal 0.3--0.6MPa Photo 10. Air pressure adjusting Attention: * Need pull button up then adjusting. When finish, please put down this button.
  • Page 15 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Step 3.Adjusting Air pressure on 0.5Mpa Step 4. Press the button into Cutting (Photo 11)and start to work Photo 11--Current Adjusting Second Step: Adjusting Current according to different...
  • Page 16 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd *Data setting is on the basic of material thickness Operation: After adjusting, now let’s start to operate. 1.move plasma head to left bottom of working piece Press X+ X- Y+ Y- ,move the x axis and y axis left bottom of working piece .as picture Photo 13...
  • Page 17 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Edit File Input ENTER...
  • Page 18 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Change working speed F button Torch height up Torch height down Start button 3. Adjust torch height : Long time press this button Show this...

  • Page 19: Maintenance

    济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Then press this button Last press this Two times button Maintenance Chapter 3 Change the Electrode Pull down the head of water pipe from plasma head...

  • Page 20: Other Point Need Pay Attention

    济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Loosen Big electrode by spanner Loose small electrode by spanner Loosen small electrode by spanner then put it out by hand. *Direction same as Big electrode.
  • Page 21 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd 7. Operator DO NOT leave during work process 8. Big water tank for water pump. 9. After changing nozzle and electrode, put water pipe lower than Nozzle 0.5-0.7mm...
  • Page 22 济 南 力 帆 机 械 设 备 有 限 公 司 Jinan Lifan Machinery Co.,Ltd Our Service Departments hereby as follow: Quality First ,Service First ,.Customer First JINAN LIFAN MACHINERY CO.,LTD Service email: service@fldcnc.com Skype: lifancnc...
