68
54.8
Specifications:
Continuous rating:
275 amps DC
Intermittent rating:
455 amps DC
Cranking rating:
1250 amps DC
Maximum Voltage:
32 volts DC
Operation:
Manual
Manual On/Off
Auto
Motorised On/Off
Mounting:
Recessed or surface
Auto Operating range:
8 to 30 volts DC
Stud Size:
2 x 10mm (3/8")
Power draw:
Switch in off position: 15mA
Max. Cable Size:
50mm
IMPORTANT
It is the installer's responsibility to fit and use this product in a manner that will not
cause accidents, personal injury or property damage. Please follow the installation
instructions supplied. If installation is not correct, the unit may not perform at its
designed potential.
Manufactured for Hella by BEP Marine Limited
100
75
53
All dimensions in mm
2
Part No: 4724
MOTORISED BATTERY SWITCH
Operation and Installation Instructions
Features
•
Ignition protected
•
Tin plated copper studs and nuts
HELLA - New Zealand Limited
81-83 Ben Lomond Crescent
Pakuranga, Auckland, New Zealand
PO Box 51427, Auckland 2140
Advertisement
Summary of Contents for Hella 4724
- Page 1 If installation is not correct, the unit may not perform at its HELLA - New Zealand Limited designed potential. 81-83 Ben Lomond Crescent Pakuranga, Auckland, New Zealand Manufactured for Hella by BEP Marine Limited PO Box 51427, Auckland 2140...
- Page 2 As a result voltage drop and use of heavy cable can be kept to a minimum. Auto Operation: The 4724 moves from a state of “Auto Off” to “Auto On” when the remotely mounted switch is turned on. During the time that the battery switch is in “Auto General Operation: On”...
