ERGOMART Corner Shaper and Keyboard Arm Installation Instructions

Corner Shaper and Keyboard Arm
1
C.
C.
Fully tighten after step 2
Pre-assemble top and bottom portions of Corner Shaper
using Barrel Nuts. (Tighten Barrel Nuts in Step 2)
3
If using the CornerShaper without a track
B.
B.
B.
B.
A.
A.
Attach Corner Shaper to the bottom of work surface
using screws A and B in their designated holes.
5
If using the CornerShaper with a track
Slide Keyboard Arm into Track
Ergonomic solutions for office and light industrial work environments

Installation Instructions

www.ergomart.com | 888 420 3200
C.
A.
A.
B.
©2014 Ergomart. All rights reserved.
r
™
2
1) Slide Corner Shaper into corner of work surface
2) Tighten Barrel Nuts (shown in step 1)
4
If using the CornerShaper with a track
Attach Corner Shaper and track to the bottom of work
surface using screws B. (Bumper purchased with track)
6
If using the CornerShaper with a track
B.
B.
Install Stop
B.
A.
Bumper
B.
