ClearCube CD7724T-L1 Quick Start Manual

Zero Client Quick Start Guide

Package Contents

• CD7724T-L1 TEMPEST zero client
• Zero client power adapter and cable
• Y-cable adapter for single-link-to-dual-link DVI (× 1 for
dual-monitor zero clients)
• This Quick Start Guide
• Included in TEMPEST bundle only: TEMPEST
display, TEMPEST keyboard, and TEMPEST mouse
Smart Card Reader Smart Card
Activity Indicator Reader
HD
Audio Out
DVI-I Connectors
USB
Port
USB
Ethernet
Port
Connector
(SFP)
ClearCube Technology, Inc.
CD7724T-L1 TEMPEST L1
Front
PCoIP Session
Indicator
USB
Power Power
Port
Indicator Button
Rear
MAC Address
and Serial Number
HD AC
Audio Out Input
3700 W Parmer Lane
CD7724T-L1 Zero Client Overview
A zero client is a remote computing device that connects a
user's monitors, keyboard, mouse, speakers, and other
peripherals to remote ClearCube
to virtual desktops (VMs). As shown below, computing
resources are typically located in remote data centers. Zero
clients enable users to work on a blade or VM as if it is a local
PC. The connection between the zero client and the remote
®
device is over PCoIP
host card manages the PCoIP session.
Network Infrastructure
Ethernet
Zero Client with Monitors
and Peripherals
Zero client connected to blade or to VM
Zero Client Features
ClearCube CD7724T-L1 zero clients connect to supported
ClearCube PC blades containing Tera1 or Tera2 host cards
and to virtual machines to provide:
• Three USB ports
• Support for fiber Ethernet media through SPF module
• Support for independently-configurable monitors
– 2 DVI monitors up to 1920 × 1200
– 1 DVI monitor up to 2560 × 1600
(requires single-link-DVI-to-dual-link-DVI Y-cable
adapter, included)
Austin, Texas 78727 (512) 652-3500
®
PC blades (computers) and
protocol. Inside the remote device, a
Ethernet
Chassis with
Blades and VMs
www.clearcube.com
