Unpacking the turnstile
First remove the top cover of the wooden crate, then the side cover. The turnstile inside the
crate can now be pulled out of the crate. Do not remove the plastic wrapping until the turn-
stile is ready to be used as this will prevent any damage to the stainless steel cabinet.
www.rotech.com.au
TRISTAR J18 AT
TURNSTILE Instructions
(V11/19)
1
e: info@rotech.com.au
Advertisement
Summary of Contents for Rotech TRISTAR J18 AT
- Page 1 Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au TRISTAR J18 AT TURNSTILE Instructions (V11/19) Unpacking the turnstile First remove the top cover of the wooden crate, then the side cover. The turnstile inside the crate can now be pulled out of the crate.
- Page 2 1. Introduction The TriStar J18 AT automatic turnstile is designed for use in high volume traffic areas to control pedestrian traffic. Any type of access control or ticketing system can be used to activate the turnstile. The turnstile is operated using a DC brushless motor which ensures a smooth operation and the inbuilt encoder guarantees exact positioning of the arm.
- Page 3 connected to the fire alarm or any type of emergency input. When the power is restored or the emergency input is switched off the arm automatically returns to the default position 3.14 The J18 AT has a memory input that remembers how many access cards have been presented and does not lock the turnstile until all users who have presented their cards have passed through the turnstile.
- Page 4 7. Z3D001A Control Panel...
- Page 5 8. Set up Instruction After power-up, the LED on the main board will display the version number of the current software. For example, the display shows 0-01, indicating that the current software is V01, The display will then show : 2017-12-12-10-41-30 (year, month, day, hour, minute, second).
- Page 6 Parameter Description Value Valu P-00 Example P-01 Counting function selection Disable Enable To allow access in entry P-02 Disable Enable direction To allow access in exit P-03 Disable Enable direction P-05 Reserved P-06 Entry control by Swiping card Free wheel P-07 Exit control by Swiping card...
- Page 7 Interface Name Pin definition The reversed panel +12V —+12V output, power for indicator status indicator GND — Power GND GND —Power GND — Reversed red indicator —Reversed blue indicator —Reversed yellow indicator +12V - +12V output, powering the panel status indicator FRL - status indicator red light FBL - status indicator blue light...
- Page 8 No response when triggered Close cover Arm is not returning to start position Check cam for wear if OK add lubricant Arm is slow returning to start position Adjust tension springs Emergency arm drop off not working or arm Adjust the position of the release solenoid won’t lock in position when power on Arm does not automatically lock in position Adjust position of photocell on disc.
- Page 9 Turnstile J18 AT Dimensions NOTE: The concrete pad should be 20Mpa (min) 150 mm thick, cured for 7 days on a suitably compacted foundation. Hold down anchors (4) to be 12mm dia x 100mm into the concrete. Control panel in Entry Leg of Turnstile.
- Page 10 Cleaning and Maintenance of Stainless steel cabinet Initial cleaning, wipe down exterior surfaces with thinners, then polish with stainless steel polish If outdoor polish every 3 months In wet environments (daily cleaning with water) polish every 4 weeks to prevent “tea staining”...
