- Page 1 User’s Manual Product Introduction & Principle Technical Specification Table Use& Safety Considerations Structure Diagram Installation Indicator& Alarm Replacement of Silver Probe...
- Page 2 Commercial Ozone Water Purifier has the main functions as below: Soft water Sterilization and disinfection; Decontamination and purification; High Efficient，Energy conservation and environmental protection； TECHNICAL SPECIFICATION TABLE Commercial Ozone Water Purifier WPOZ2.0-E3 Model Input: AC 100-240V/50-60Hz Electrical Output: DC 12V 7.5A 90W 0.8~2.0 mg / L...
- Page 3 USE & SAFETY CONSIDERATION Before using, please read the User’s Manual carefully. ⌧Do not operate the unit with the cover removed. ⌧Disconnect ALL power before servicing. ⌧Do not mount this Commercial Ozone Water Purifier vertically or at an angle. ⌧Do not use an extension cord or a different power adapter (other than the one provided with your Commercial Ozone Water Purifier with this appliance).
- Page 4 STRUCTURE DIAGRAM Note 1： Part 4 & Part 5 are optional items. Standard products do not include these two parts. CONTROL PANEL DIAGRAM Normal Abnormal Part Name State State UV Light Blue Ozone Blue Water Leakage Gray Red Light indicates one part works abnormally.
- Page 5 INSTALLATION INSTRUCTION 1. Commercial Ozone Water Purifier will offer two metallic plates, a power adapter, 4-1/4 tapping screws, a hose, and a screwdriver as accessories. 2. Commercial Ozone Water Purifier should be fastened to the wall, left above your tap. Firstly, fix the metallic plate on the wall.
- Page 6 System Set Up 1. Turn on the water valve/faucet. Check the connections to ensure that there is no leakage or dripping. Tighten the hose connections, if necessary, but DO NOT over tight. 2. Connect power adapter, and then start your washer. Once the water begins to flow, the blue light of Commercial Ozone Water Purifier should begin to glow.
- Page 7 MAINTENANCE SERVICE Your Commercial Purifier is warranted to be free from all defects in material and workmanship in normal household use for a period of (1) year from date of purchase. The warranty is granted only to the original purchaser and members of his or her immediate household.
