P&E PE-9401 User Manual & Installation Manual

is wireless sound and flash light siren, smart human design, built-in emitting antenna / louder siren, it
PE-9401
can work with wireless alarm control panel or other wireless equipments (max 15) via wireless signal transmission,
and also can work separately, when wireless PIR detector had been triggered and send out the wireless alarm
signal to siren, it can make the alarm and flash light by itself, it has anti-remove function via built-in magnetic
module on bracket, make alarm when siren had been took away from bracket under arm status, more suitable
install on corridor, outside window, eave etc...
Features:
1. support 15 wireless equipments
2. support wireless alarm control panel, PIR detector, door / window detector etc...wireless equipment
3. dual-way communicate with wireless alarm control panel
4. high alarm volume around 100dB via built-in siren
5. sound for 2.5 minutes when alarm had been triggered if without
disarm
6. sound indication for arm/disarm
7. anti-remove function via built-in magnetic module on bracket,
make alarm when siren had been took away from bracket under
arm status
8. wireless emitting frequency: 433MHz / 868MHz
9. wireless emitting range is 100m (in open area)
10. consumption current is 8mA (static) / ≤500mA (alarm)
11. built-in rechargeable battery 12V/500mA up to 8 hours when power off
12. included 18V/1000mA external power adapter
13. dimension is Φ127mm / blue/white or red/white color
Installation:
drill hole
1
install bracket on the wall
3. fix the siren back side pothook to the holes of
bracket, push it down after inserted the holes,
double check the stable after installed
Warning: we are not responsible for the problem caused by improper operation or change the product
configuration, it may lose the authority of product warranty!
PE-9401 – Wireless Sound and Light Siren
2
siren fixed hole
1. mark the drill hole and drill holes on the wall
accordingly;
2. using the screws with countersink heads, so
that fix the bracket on the wall.
3
install siren with fixed bracket
1
User Manual / Installation Guide

User Manual
